3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch

3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch

  • 3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch
3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q614
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Ball Power: Pneumatic
Pipe Connection: Female Thread Body Material: Cast Steel, SS304, SS316
Seal Material: PTFE, TFM Working Medium: Neutral Gas, Air
Port Size: 1/2'' To 2'' Way Number: 3 Way
Flow Direction: L Pattern, T Pattern Medium Temperature: PTFE: -20 To +180℃, TFM: -30 To +230℃
High Light:

3 Way Pneumatic Ball Valve

,

Pneumatic Ball Valve With Solenoid Valve

,

Pneumatic Ball Valve With Limit Switch

3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch



Pneumatic actuated 3-way ball valves, which are used to control the flow of liquids and gases remotely. The actuator will open and close the ball valve with compressed air (single acting uses a spring to either open or close the valve). The ball valve has a hole through one side to allow flow when turned appropriately. These valves are 3-way valves (3 ports) and offer good sealing properties. Available with L-bore or T-bore. Pneumatic actuators are a reliable solution and often used to control larger valves than electric actuators at a lower investment cost. There are various housings, seals, and sizes of pneumatically controlled ball valves to allow you to find the right one for your application.



Technical Data of Pneumatic Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Flow Direction of 3 Way Pneumatic Ball Valve:

3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 0



Main Dimension of Pneumatic Ball Valve:

3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 1

3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 2



More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 3 3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 4 3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 5 3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 6
3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 7 3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 8 3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 9 3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 10
Pneumatic Butterfly Valves
3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 11 3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 12 3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 13 3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch 14



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
