Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch

Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch

  • Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch
Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q611
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Ball Power: Pneumatic
Pipe Connection: Female Thread Body Material: Stainless Steel (304, 316)
Seal Material: PTFE, TFM Working Medium: Neutral Gas, Air
Port Size: 1/2'' To 4''
High Light:

Pneumatic Ball Valve With Solenoid Valve

,

Pneumatic Ball Valve With Limit Switch

,

Pneumatic Actuated Ball Valve

Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch



Pneumatic Actuated Ball Valve offered by BRANO helps to automatically control the fluid flow using BRANO pneumatic rotary actuator. BRANDO makes high quality Investment casted ball valves with ISO 5211 mounting pad are very much suitable for direct mounting of Pneumatic Actuator on Ball Valves. The Actuator used is of Single acting and Double acting depending upon the application. Single acting actuator is used where power fails causes valve to close. On the other hand, Double acting actuator is used where differential pressure on both the supply ports which leads to open and close the valve.



Main components of ball valve include Body, Ball, Seat (PTFE, RPTFE, CFT, Viton etc), Stem, Gland, and Lever. Ball valve is a quarter turn valve which is operated by rotating the ball at its axis to open and close the fluid flow. Ball Valve provides bubble tight shutoff as it uses Soft seat for sealing. Also, the Ball Valve is highly resistant to contaminated media as compared to other valves. BRANO offers Ball valve in 2-Piece and 3- Piece design available in Screwed , Socket and flanged end as per international standards.



Technical Data of Pneumatic Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Main Dimension of Pneumatic Ball Valve:

Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 0

Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 1



More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 2 Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 3 Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 4 Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 5
Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 6 Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 7 Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 8 Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 9
Pneumatic Butterfly Valves
Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 10 Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 11 Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 12 Pneumatic Actuated Ball Valve With Solenoid Valve Limit Switch 13



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
