1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator

1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator

  • 1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator
1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q611
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Ball Power: Pneumatic
Pipe Connection: Female Thread Body Material: Stainless Steel (304, 316)
Seal Material: PTFE, TFM Working Medium: Neutral Gas, Air
Port Size: 1/2'' To 4''
High Light:

Pneumatic Ball Valve 1''

,

2 Way Pneumatic Ball Valve

,

Pneumatic Operated Ball Valve

1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator



Our Pneumatic Actuated 2 Way Stainless Steel Ball Valve is a non-maintainable two piece, full bore ball valve for general purpose, industrial and chemical applications; water treatment, chemical, slightly corrosive and semi aggressive fluids. A reliable pneumatically actuated valve with Stainless Steel body and PTFE seat. Actuation is either Single or Double acting with a range of configurable options including limit switches, solenoid valves and positioners.



Technical Data of Pneumatic Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Main Dimension of Pneumatic Ball Valve:

1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 0

1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 1



More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 2 1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 3 1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 4 1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 5
1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 6 1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 7 1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 8 1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 9
Pneumatic Butterfly Valves
1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 10 1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 11 1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 12 1'' 2 Way Air Actuated Ball Valve With Pneuamtic Actuator 13



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
