2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator

2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator

  • 2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator
2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q611
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Ball Power: Pneumatic
Pipe Connection: Female Thread Body Material: Stainless Steel (304, 316)
Seal Material: PTFE, TFM Working Medium: Neutral Gas, Air
Port Size: 1/2'' To 4''
High Light:

2 Inch Pneumatic Ball Valve

,

Air Operated Ball Valve

,

Pneumatic Driven Ball Valve

2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator



Pneumatic stainless steel ball valves have stainless steel as their housing material. They are typically used for aggressive and corrosive media. Stainless steel is also highly wear, temperature, and pressure resistant.



Pneumatic actuators control ball valves by the conversion of compressed air energy to mechanical motion. A rotary mechanical motion is required in a ball valve for a 90 degrees turn. Pneumatic actuator ball valves can be single-acting or double-acting. A single-acting pneumatic actuator uses a single compressed air input to turn the valve and a spring to return the valve to the normal position. A double-acting pneumatic actuator has two compressed air inputs to turn the valve and return the valve to the original position.



Technical Data of Pneumatic Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Main Dimension of Pneumatic Ball Valve:

2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 0

2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 1



More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 2 2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 3 2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 4 2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 5
2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 6 2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 7 2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 8 2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 9
Pneumatic Butterfly Valves
2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 10 2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 11 2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 12 2 Inch SS304 Air Operated Ball Valve With Pneuamtic Actuator 13
