DN50 Pneumatic Actuated Three-Piece Ball Valve Stainless Steel 304

DN50 Pneumatic Actuated Three-Piece Ball Valve Stainless Steel 304

A 2-way ball valve has 2 ports, an inlet and an outlet, making it a straight ball valve. Therefore, media will only flow in one direction and they are considered inline ball valves with the rest of the assembly. The ball valve is controlled and turned by the pneumatic actuator. If the valve is open, then the media will flow from the inlet, through the ball's bore, and out the outlet. If the valve is closed, then the media flow is shut off. They are often called an on/off ball valve with pneumatic actuator.

A pneumatic actuator requires compressed air to operate. The actuator can either be single or double acting. A single acting pneumatic actuator uses compressed air to rotate the ball in one direction and uses a spring to move it back to the normal position. A double acting pneumatic actuator requires compressed air to move the ball in either direction.

Technical Data of Pneumatic Ball Valve:

Main Dimension of Pneumatic Ball Valve:

More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
Pneumatic Butterfly Valves
