Place of Origin: | China |
Brand Name: | Brando |
Certification: | CE |
Model Number: | Q641 |
Minimum Order Quantity: | 1 pc |
---|---|
Price: | Negotiation |
Packaging Details: | Inner boxes, Carton, Pallet |
Delivery Time: | 4-8 days |
Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
Supply Ability: | 50000 pcs per month |
Structure: | Ball | Power: | Pneumatic |
---|---|---|---|
Pipe Connection: | Flanged | Body Material: | Stainless Steel (304, 316) |
Seal Material: | PTFE, TFM | Working Medium: | Neutral Gas, Air |
Orifice Size: | DN15 To DN200 | ||
Highlight: | 2'' Pneumatic Ball Valve,Pneumatic Operated Ball Valve,Pneumatic Flanged Ball Valve |
2'' Pneumatic Operated Flanged Ball Valve Stainless Steel 304
A pneumatic actuated ball valve can be broken down into two main components. The pneumatic actuator and the ball valve. For a 2-way ball valve, the pneumatic actuator can turn the ball 90 degrees to be either fully open or fully closed. For a 3-way valve, the pneumatic actuator can turn the ball between different circuits depending if it is an L-port or T-port ball valve. They are mounted together typically with a standard flange adhereing to ISO 5211. This allows both the pneumatic actuator or ball valve to be swapped out with another one using the same flange size.
A pneumatic actuator requires compressed air to operate. The actuator can either be single or double acting. A single acting pneumatic actuator uses compressed air to rotate the ball in one direction and uses a spring to move it back to the normal position. A double acting pneumatic actuator requires compressed air to move the ball in either direction. An air actuated ball valve is a reliable solution and often a lower investment cost for larger valves compared to an electric ball valve. There are various housings and sizes of pneumatic ball valves to allow you to find the right one for your application. Air operated ball valves are commonely used for remote control of a flow, like a water pipe or air hose.
Technical Data of Pneumatic Ball Valve:
Main Dimension of Pneumatic Ball Valve:
More Pneumatic Actuator Valves for you to choose:
Pneumatic Ball Valves | |||
Pneumatic Butterfly Valves | |||
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
