| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | VX31 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Port Size: | 1/8'', 1/4'' | Orifice Size: | 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm |
|---|---|---|---|
| Operation Mode: | 2 Way, Normally Closed | Action: | Direct Acting |
| Body Material: | Brass, Stainless Steel | Seal Material: | NBR, EPDM, FKM |
| Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | Pressure Range: | 0 To 1 MPa |
| High Light: | 3 Way NC Solenoid Valve,3 Way Solenoid Valve 24V,3 Way Solenoid Valve For Water |
||
VX31 SMC Type 3 Way NC Brass Solenoid Valve 1/8'' 1/4'' 24V 220V
The multi-purpose 3/2 way direct acting solenoid valves are mainly suitable in the neutral gaseous and liquid fluid pipeline automatically control. It is suitable the medium of gas, water, oil, vacuum, steam. Can be operated with zero pressure difference & circulation direction is random.
Main Dimension of VX Series Solenoid Valve:
Technical Data of VX Series Solenoid Valve:
|
Model
|
Function
|
Orifice Size
(mm)
|
Port Size
(inch)
|
CV
|
Working Pressure (bar)
|
Medium Temperature
|
|
|
AC
|
DC
|
||||||
|
VX31
|
3 Way, Normally Closed
|
1.5
|
1/8'', 1/4''
|
0.07
|
13
|
11
|
NBR: -5 to +85℃,
EPDM: -5 to +150℃,
FKM: -10 to +150℃
|
|
2.0
|
0.14
|
11
|
9
|
||||
|
2.5
|
0.21
|
9
|
7
|
||||
|
3.0
|
0.25
|
6
|
4
|
||||
|
4.0
|
0.35
|
3.5
|
2
|
||||
|
VX32
|
3 Way, Normally Open
|
1.5
|
0.07
|
13
|
11
|
||
|
2.0
|
0.14
|
11
|
9
|
||||
|
2.5
|
0.21
|
9
|
7
|
||||
|
3.0
|
0.25
|
6
|
4
|
||||
|
4.0
|
0.35
|
3.5
|
2
|
||||
|
VX33
|
3 Way, Universal Operation
|
1.5
|
0.07
|
13
|
11
|
||
|
2.0
|
0.14
|
11
|
9
|
||||
|
2.5
|
0.21
|
9
|
7
|
||||
|
3.0
|
0.25
|
6
|
4
|
||||
|
4.0
|
0.35
|
3.5
|
2
|
||||
Working flow direction of VX Series Solenoid Valve:
Brando Factory Production of Solenoid Valves:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
