| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | VX2120-02 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Port Size: | 1/4'' | Orifice Size: | 3mm |
|---|---|---|---|
| Operation Mode: | 2 Way, Normally Closed | Action: | Direct Acting |
| Body Material: | Brass | Seal Material: | NBR, EPDM, FKM |
| Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | Pressure Range: | 0 To 1 MPa |
| High Light: | Brass Solenoid Valve SMC,SMC Solenoid Valve 24V,SMC VX2120-02 |
||
VX2120-02 SMC Type Brass Solenoid Valve 2/2 Way NC 1/4'' 24V 220V
The VX2 series is 2 port direct solenoid valve for general purpose air, medium vacuum and water. Available body materials include brass or stainless steel with port size up to 1/2 inch.NBR seal is used as standard and FKM or EPDM is optional. Flow rate ranges from Cv of 0.23 to 2.21.
1. IP65 enclosure
2. Normally Closed and Normally Open type available, Class B coil
3. Body material: brass, stainless steel
4. Working pressure range: 0 to 1 MPa
Main Dimension of VX2 Series Solenoid Valve:
|
VX Series
|
A
|
B
|
C
|
D
|
|
VX2122-01
|
25
|
40
|
70
|
1/8''
|
|
VX2222-02
|
1/4''
|
|||
|
VX2120-01
|
45
|
1/8''
|
||
|
VX2120-06
|
45
|
1/4''
|
||
|
VX2260-03
|
40
|
48
|
80
|
3/8''
|
|
VX2360-03
|
3/8''
|
|||
|
VX2360-04
|
48
|
68
|
110
|
1/2''
|
Technical Data of VX2 Series Solenoid Valve:
|
Model
|
VX2112-01
|
VX2112-02
|
VX2120-01
|
VX2120-02
|
VX2260-03
|
VX2360-03
|
VX2360-04
|
|
Orifice Size
|
2mm
|
2mm
|
3mm
|
3mm
|
10mm
|
10mm
|
10mm
|
|
Port Size
|
1/8''
|
1/4''
|
1/8''
|
1/4''
|
3/8''
|
3/8''
|
1/2''
|
|
Medium
|
Water, Oil, Gas, Steam
|
||||||
|
Action
|
Direct Acting
|
||||||
|
NC/NO
|
Normally Open
|
Normally Closed
|
|||||
|
Body Material
|
Brass, Stainless Steel
|
||||||
|
Seal Material
|
NBR, FKM
|
||||||
|
Pressure
Range
|
0 to 1.0Mpa
|
||||||
|
Temp. Range
|
NBR: (-5 to +80℃), FKM: (-5 to +150℃)
|
||||||
Brando Factory Production of Solenoid Valves:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
