Q22HD-25 1'' DN25 2/2 Way Pneumatically Operated Piston Valve

Q22HD-25 1'' DN25 2/2 Way Pneumatically Operated Piston Valve

  • Q22HD-25 1'' DN25 2/2 Way Pneumatically Operated Piston Valve
Q22HD-25 1'' DN25 2/2 Way Pneumatically Operated Piston Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q22HD-25
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Port Size: 1'' Orifice Size: 25mm
Action: Double Acting, Single Acting Working Fluids: Air, Water, Oil, Gas
Body Material: Brass Seal Material: NBR, EPDM, FKM
Pressure Range: 0 To 1 MPa Temperature Range: NBR: -5 To +80℃, EPDM, FKM: -5 To +150℃
High Light:

Pneumatically Operated Piston Valve

,

Pneumatic Control Piston Valve

,

Pneumatic Piston Type Valve

Q22HD-25 1'' DN25 2/2 Way Pneumatically Operated Piston Valve



Air operated valves, also known as pneumatic piston valves or air operated piston valves are designed to function effectively in a wide range of high demanding industry applications. Often used in applications where there is excess ambient temperature or high-pressure steam duty, air operated valves are multifunctional and can be used with varying media, including: air, water, hydraulic oil and steam.



In order to allow the valves to operate effectively with dangerous media, the piston valve material has to be durable. Air operated valves from BRANDO are manufactured from only the most hard-wearing and robust material selection, including bronze, brass and stainless steel. These materials are recognised for their ability to operate in hazardous environments without damaging the service life of the valve.



Main Dimension of Pneumatic Control Piston Valve:

    Q22HD-25 1'' DN25 2/2 Way Pneumatically Operated Piston Valve 0

Model
A
B
C
D
H
M
Q22HD-15
48
26
30
1/2''
96
1/8''
Q22HD-20
55
32
37
3/4''
107
Q22HD-25
66
38
37
1''
118
Q22HD-35
84
49
66
1 1/4''
162
Q22HD-40
84
54
66
1 1/2''
162
Q22HD-50
102
66
80
2''
180



Technical Data of Pneumatic Control Piston Valve:

Model
Q22HD-15
Q22HD-20
Q22HD-25
Q22HD-35
Q22HD-40
Q22HD-50
Port Size
1/2''
3/4''
1''
1 1/4''
1 1/2''



2''
Orifice Size
15mm
20mm
25mm
35mm
40mm
50mm
Body Material
Brass
Working Medium
Air, Water, Oil, Liquefied Gas, Free-runing Viscosity Liquid
Action
Double Acting, Single Acting
Pressure Range
0 to 1 MPa

Meidum

Temperature
NBR: -5 to +80℃, EPDM, FKM: -5 to +150℃
Kv Value
4
5
10
25
25
40


Brando Factory Production of Solenoid Valves:
