Name: PU220A-08 Shako Type 2 Way NC Brass Solenoid Valve 1'' 220V AC
Brand: Brando
SKU: PU220A-08
Rating: 4.6 (169 reviews)

Home Products Brass Solenoid Valve

PU220A-08 Shako Type 2 Way NC Brass Solenoid Valve 1'' 220V AC

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	PU220A-08

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability:	300000 sets per month

Contact Now

Detailed Product Description

Port Size:	1''	Orifice Size:	25mm
Function:	2 Way, Normally Closed	Operation:	Assisted Lift
Body Material:	Brass	Seal Material:	NBR
Voltages:	24VDC, 110VAC, 220VAC	Working Pressure Range:	0 To 7 Kg/cm²
High Light:	Brass Solenoid Valve 220V , Shako Solenoid Valve PU220 , Shako PU220A-08

PU220A-08 Shako Type 2 Way NC Brass Solenoid Valve 1'' 220V AC

PU220A brass zero rated General purpose 2/2 Way normally closed solenoid valve.

1. Port Sizes: 3/8" PU220A-03, 1/2" PU220A-04, 3/4" PU220A-06 and 1" PU220A-08.

2. Port Options: BSP, NPT thread or flanged PN16, ANSI150Lb or JIS10K

3. Construction: Body die cast Brass SS41, Stainless steel internals one piece core tube, 430F armature and 302 springs to extend solenoid valve life.

4. Seal options: NBR Pu220A, EPDM PO220AE or FKM PU220AV all with nylon reinforcement and 304 stainless steel strengthening and support disk.

5. Pressure Range: 0 to 7 Bar with 15 watt coil, 0 to 16 bar with 18.5 watt Coil

6. Voltages: 12VDC, 24VDC, 48VDC, 110VDC, 220VDC or 12VAC, 24VAC, 48VAC, 110VAC, 220VAC, 230VAC, 240VAC, 380VAC and 415VAC

7. Option: ATEX EExmIIT4 Hazardous area zone 21 and 22.

8. PU220A solenoid valves are all 10 Bar pressure, function and leak tested prior to despatch.

Main Dimension of PU220A series Solenoid Valve:

PU220A-08 Shako Type 2 Way NC Brass Solenoid Valve 1'' 220V AC 0

PU220 Series	A	B	C	R
PU220A-03	66.5	101	48	3/8''
PU220A-04	66.5	101	48	1/2''
PU220A-06	71	107	58	3/4''
PU220A-08	96	120.5	70	1''

Technical Data of PU220A series Solenoid Valve:

PU220A Series	PU220A-03	PU220A-04	PU220A-06	PU220A-08
Orifice Size	13.0mm	13.0mm	20.0mm	25.0mm
Port Size	3/8''	1/2''	3/4''	1''
Effective Area	76mm²	76mm²	162mm²	220mm²
Cv Value	4.00	4.00	8.60	11.0
Medium	Compressed Air, Light oil, Water
Action	Assisted Lift
Function	2 Way, Normally Closed
Body Material	Brass
Pressure Range (bar)	0 to 7 kg/cm²
Temperature Range	NBR: -5 to +80℃, EPDM: -5 to +120℃, FKM: -10 to +150℃, Si: -15 to 150℃
Duty Cycle	100% ED
Coil Type	DIN
Protection Class	IP65
Insulation Class	F
Standard Voltages	24VDC, 110VAC, 220VAC, the other voltage is optional
