| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | D |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PVC bag, then inner box, then carton, then pallet |
| Delivery Time: | 1 week after payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Silencer Muffler | Tube OD (Inch): | 1/8", 1/4'', 3/8'', 1/2'', 3/4'', 1'' |
|---|---|---|---|
| Material: | Brass | Working Pressure Range: | 0 To 0.8MPa |
| Working Temperature: | -10 To +250℃ | Working Medium: | Compressed Air |
| High Light: | Pneumatic Valve Exhaust Silencer,Pneumatic Valve Exhaust Muffler,Brass Pneumatic Silencer |
||
Brass Pneumatic Solenoid Valve Exhaust Silencer Muffler 1/8'' 1/4''
Pneumatic Silencers are installed directly into the exhaust port of pneumatic valves and equipment. They work by diffusing the released air via a larger surface area. This, in turn, reduces the turbulence and decreases noise levels.
The two most common types of silencer are conical or flat. Both designs come in a range of different working pressure and temperature ratings, connection types and housing materials both metal and plastic. The application will influence the type of silencer selected.
Technical data of Pneumatic Silencer Muffler:
|
Model
|
Working Medium
|
Working Pressure
(MPa)
|
Working Temp
(℃)
|
Circulation Capacity
|
Noise Effect
|
|
|
"S" data
|
Nominal Flux
|
|||||
|
-2.5
|
Compressed Air
|
0 to 0.8
|
-10 to +250
|
5
|
200L/Min
|
≥20dB
|
|
-6
|
20
|
960L/Min
|
||||
|
-8
|
40
|
1920L/Min
|
||||
|
-10
|
60
|
2880L/Min
|
||||
|
-15
|
110
|
5280L/Min
|
||||
|
-20
|
190
|
9120L/Min
|
||||
|
-25
|
300
|
10000L/Min
|
||||
|
-32
|
400
|
19200L/Min
|
≥25dB
|
|||
|
-40
|
650
|
31200L/Min
|
||||
|
-55
|
700
|
33600L/Min
|
||||
Dimension of Pneumatic Silencer Muffler:
|
Model No
|
M
|
L1
|
L
|
H
|
K
|
|
D-6
|
G1/8''
|
6
|
21
|
2
|
2
|
|
D-8
|
G1/4''
|
9
|
27
|
2
|
2
|
|
D-10
|
G3/8''
|
11
|
36
|
2
|
2
|
|
D-15
|
G1/2''
|
11
|
44
|
2
|
3
|
|
D-20
|
G3/4'
|
12
|
65
|
3
|
3
|
|
D-25
|
G1''
|
15
|
75
|
4
|
4
|
