| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | G |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PVC bag, then inner box, then carton, then pallet |
| Delivery Time: | 1 week after payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Silencer Muffler | Tube OD (Inch): | 1/8", 1/4'' |
|---|---|---|---|
| Material: | Brass | Working Pressure Range: | 0 To 0.8MPa |
| Working Temperature: | -10 To +250℃ | Working Medium: | Compressed Air |
| High Light: | Solenoid Valve Exhaust Muffler,Solenoid Valve Exhaust Silencer,Pneumatic Solenoid Valve Muffler |
||
Brass Solenoid Valve Pneumatic Muffler Filter Noise Silencer 1/8'' 1/4''
Housing Materials:
The housing material of your silencer should be carefully considered when making your selection, application and environment will influence this. There are various housing materials available, the most common being sintered brass, sintered bronze and stainless steel.
Connection Types:
Most pneumatic silencers have a threaded male connection, or alternatively, they can have a push-in hose connection. Thread standards include BSP (British Standard Pipe) these can be BSPP (parallel or G) or BSPT (tapered or R). Other threads types are NPT (National Pipe Thread) or Metric, M3, M5, M7.
Technical data of Pneumatic Silencer Muffler:
|
Model
|
Working Medium
|
Working Pressure
(MPa)
|
Working Temp
(℃)
|
Circulation Capacity
|
Noise Effect
|
|
|
"S" data
|
Nominal Flux
|
|||||
|
-2.5
|
Compressed Air
|
0 to 0.8
|
-10 to +250
|
5
|
200L/Min
|
≥20dB
|
|
-6
|
20
|
960L/Min
|
||||
|
-8
|
40
|
1920L/Min
|
||||
|
-10
|
60
|
2880L/Min
|
||||
|
-15
|
110
|
5280L/Min
|
||||
|
-20
|
190
|
9120L/Min
|
||||
|
-25
|
300
|
10000L/Min
|
||||
|
-32
|
400
|
19200L/Min
|
≥25dB
|
|||
|
-40
|
650
|
31200L/Min
|
||||
|
-55
|
700
|
33600L/Min
|
||||
Dimension of Pneumatic Silencer Muffler:
|
Model No
|
M
|
L
|
D
|
S
|
|
G-6
|
1/8''
|
60
|
7
|
5
|
|
G-8
|
1/4''
|
64
|
8
|
5
|
