Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4''

Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4''

  • Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4''
Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4''
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: E
Payment & Shipping Terms:
Minimum Order Quantity: 5 pcs
Price: Negotiation
Packaging Details: PVC bag, then inner box, then carton, then pallet
Delivery Time: 1 week after payment
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 10000000pcs per month
Contact Now
Detailed Product Description
Product Name: Pneumatic Silencer Muffler Tube OD (Inch): 1/8", 1/4'', 3/8'', 1/2'', 3/4'', 1''
Material: Sintered Bronze Working Pressure Range: 0 To 0.8MPa
Working Temperature: -10 To +250℃ Working Medium: Compressed Air
High Light:

Pneumatic Valve Silencer

,

Air Cylinder Muffler

,

Pneumatic Silencer Sintered Bronze

Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4''



Pneumatic silencers are used in pneumatic systems to safely vent pressurized air to the atmosphere. Also known as mufflers they are typically used with valves, manifolds, cylinders, compressors and fittings.



Vented air that exits from an exhaust port can be so powerful it can produce a noise loud enough to be harmful to the environment or workers. Additionally, the exhausted air can also contain contaminants during operation. A silencer is a cost-effective solution used for noise reduction and to remove unwanted contaminants from clogging pneumatic systems.



Technical data of Pneumatic Silencer Muffler:

Model
Working Medium
Working Pressure
(MPa)
Working Temp
(℃)
Circulation Capacity
Noise Effect
"S" data
Nominal Flux
-2.5
Compressed Air
0 to 0.8
-10 to +250
5
200L/Min
≥20dB
-6
20
960L/Min
-8
40
1920L/Min
-10
60
2880L/Min
-15
110
5280L/Min
-20
190
9120L/Min
-25
300
10000L/Min
-32
400
19200L/Min
≥25dB
-40
650
31200L/Min
-55
700
33600L/Min


Dimension of Pneumatic Silencer Muffler:

                       Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 0

Model No
M
L1
L
S
E-6
G1/8''
6
28
13
E-8
G1/4''
8
34
17
E-10
G3/8''
10
36
22
E-15
G1/2''
12
44
27
E-20
G3/4'
14
54
32
E-25
G1''
16
66
41


List of other Brass Pneumatic Air Muffler:

Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 1 Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 2 Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 3 Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 4
Throttle Valve C Type Throttle Valve PTV Throttle Valve SD Timing Muffler
Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 5 Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 6 Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 7 Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 8
Muffler (Sintered) Muffler (Flat Head) LM Aluminous Muffler G Type Muffler
Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 9 Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 10 Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 11 Sintered Bronze Air Cylinder Pneumatic Valve Silencer Muffler 1/4'' 12
D Type Muffler E Type Muffler PSU Plastic Muffler SU Plastic Muffler
