| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | S-LM |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PVC bag, then inner box, then carton, then pallet |
| Delivery Time: | 1 week after payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Silencer Muffler | Tube OD (Inch): | 1/8", 1/4'', 3/8'', 1/2'', 3/4'', 1'' |
|---|---|---|---|
| Material: | Aluminum Alloy | Working Pressure Range: | 0 To 0.8MPa |
| Working Temperature: | -10 To +250℃ | Working Medium: | Compressed Air |
| High Light: | Air Cylinder Silencer,Air Cylinder Muffler,Pneumatic Cylinder Silencer |
||
Aluminum Alloy Pneumatic Air Cylinder Silencer Muffler 1/8" 1/4'' 3/8''
Common materials for pneumatic silencers:
You can find a wide range of materials used for pneumatic mufflers and silencers, all designed to operate in different environments with specific temperatures and pressure ranges in mind. The material used can also affect how effective a pneumatic silencer is at reducing noise. These materials include:
1. Sintered brass, can offer a lower cost with durable metal housing
2. Sintered plastic, which can be low cost and lightweight with a high chemical-resistance
3. Resin, another low-cost option that offers versatile designs depending on requirements
4. Stainless steel, offers corrosion protection, durability, and suitability for sterile environments
Technical data of Pneumatic Silencer Muffler:
|
Model
|
Working Medium
|
Working Pressure
(MPa)
|
Working Temp
(℃)
|
Circulation Capacity
|
Noise Effect
|
|
|
"S" data
|
Nominal Flux
|
|||||
|
-2.5
|
Compressed Air
|
0 to 0.8
|
-10 to +250
|
5
|
200L/Min
|
≥20dB
|
|
-6
|
20
|
960L/Min
|
||||
|
-8
|
40
|
1920L/Min
|
||||
|
-10
|
60
|
2880L/Min
|
||||
|
-15
|
110
|
5280L/Min
|
||||
|
-20
|
190
|
9120L/Min
|
||||
|
-25
|
300
|
10000L/Min
|
||||
|
-32
|
400
|
19200L/Min
|
≥25dB
|
|||
|
-40
|
650
|
31200L/Min
|
||||
|
-55
|
700
|
33600L/Min
|
||||
Dimension of Pneumatic Silencer Muffler:
|
Model No
|
M
|
S
|
|
S-LM06
|
1/8''
|
13
|
|
S-LM08
|
1/4''
|
14
|
|
S-LM10
|
3/8''
|
17
|
|
S-LM15
|
1/2''
|
22
|
|
S-LM20
|
3/4''
|
27
|
|
S-LM25
|
1''
|
34
|
List of other Brass Pneumatic Air Muffler:
|
|
|
|
| Throttle Valve | C Type Throttle Valve | PTV Throttle Valve | SD Timing Muffler |
|
|
|
|
| Muffler (Sintered) | Muffler (Flat Head) | LM Aluminous Muffler | G Type Muffler |
|
|
|
|
| D Type Muffler | E Type Muffler | PSU Plastic Muffler | SU Plastic Muffler |
More Pneumatic Products for you to choose:
| 2/2 Way Pneumatic Valve | 3/2 Way Pneumatic Valve | 5/2 Way Pneumatic Valve | 5/3 Way Pneumatic Valve |
|
|
|
|
| Namur Solenoid Valve | Air Filter Regulator Lubricator | Pneumatic Cylinder | Silcencers And Fittings |
|
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Brandon
Tel: +8613454729544
