| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | PTV |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PVC bag, then inner box, then carton, then pallet |
| Delivery Time: | 1 week after payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Silencer Throttle Valve | Tube OD (Inch): | 1/8", 1/4'', 3/8'', 1/2'', 3/4'', 1'' |
|---|---|---|---|
| Material: | Plastic | Working Pressure Range: | 0 To 0.8MPa |
| Working Temperature: | -10 To +250℃ | Working Medium: | Compressed Air |
| High Light: | Pneumatic Silencer Throttle Valve,Throttle Valve With Silencer,Pneumatic Silencer Plastic |
||
Plastic Pneumatic Air Silencer Throttle Valve 1/8'' 1/4'' 3/8'' 1/2''
Noise from pneumatic valves is extremely hazardous. A simple countermeasure is to fit the pneumatic valve’s outlet ports with pneumatic mufflers. While this reduces noise, it often disrupts operations. A well-known problem with conventional pneumatic mufflers is that the filter sooner or later gets clogged by contaminants. In certain cases, noise suppression is given a lower priority due to clogging problems.
BRANDO’s pneumatic mufflers have built-in warning indicators. In a nutshell, the technology allows the muffler itself to set the optimal combination of flow capacity and noise reduction thanks to a dynamic internal filter that minimizes operational disruptions.
Technical data of Pneumatic Silencer Muffler:
|
Model
|
Working Medium
|
Working Pressure
(MPa)
|
Working Temp
(℃)
|
Circulation Capacity
|
Noise Effect
|
|
|
"S" data
|
Nominal Flux
|
|||||
|
-2.5
|
Compressed Air
|
0 to 0.8
|
-10 to +250
|
5
|
200L/Min
|
≥20dB
|
|
-6
|
20
|
960L/Min
|
||||
|
-8
|
40
|
1920L/Min
|
||||
|
-10
|
60
|
2880L/Min
|
||||
|
-15
|
110
|
5280L/Min
|
||||
|
-20
|
190
|
9120L/Min
|
||||
|
-25
|
300
|
10000L/Min
|
||||
|
-32
|
400
|
19200L/Min
|
≥25dB
|
|||
|
-40
|
650
|
31200L/Min
|
||||
|
-55
|
700
|
33600L/Min
|
||||
Dimension of Pneumatic Silencer Muffler:
|
Model No
|
M
|
S
|
|
PTV06
|
1/8''
|
13
|
|
PTV08
|
1/4''
|
14
|
|
PTV10
|
3/8''
|
17
|
|
PTV15
|
1/2''
|
22
|
|
PTV20
|
3/4''
|
27
|
|
PTV25
|
1''
|
34
|
