| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | C |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PVC bag, then inner box, then carton, then pallet |
| Delivery Time: | 1 week after payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Silencer Throttle Valve | Tube OD (Inch): | 1/8", 1/4'', 3/8'', 1/2'', 3/4'', 1'' |
|---|---|---|---|
| Material: | Sintered Bronze | Working Pressure Range: | 0 To 0.8MPa |
| Working Temperature: | -10 To +250℃ | Working Medium: | Compressed Air |
| High Light: | Pneumatic Silencer Sintered Bronze,Throttle Valve With Silencer,Adjustable Pneumatic Muffler |
||
Adjustable Pneumatic Throttle Valve With Silencer Sintered Bronze
Pneumatic silencer throttle valve:
Throttle valves are commonly included with silencers and are commonly just called adjustable pneumatic silencers or flow control silencers. Adjustable pneumatic silencers are an inexpensive method for pneumatic flow control to control the speed at which air exits the valve. For example, by controlling the exhaust speed of a pneumatic cylinder you can control how quickly the piston is able to extend and/or retract. The flow rate of air is typically adjusted by rotating a knob to change the flow speed, like a needle valve. The position of the screw will increase or decrease the size of the valve orifice and thus adjust the flowrate of the air exiting the valve.
Technical data of Pneumatic Silencer Muffler:
|
Model
|
Working Medium
|
Working Pressure
(MPa)
|
Working Temp
(℃)
|
Circulation Capacity
|
Noise Effect
|
|
|
"S" data
|
Nominal Flux
|
|||||
|
-2.5
|
Compressed Air
|
0 to 0.8
|
-10 to +250
|
5
|
200L/Min
|
≥20dB
|
|
-6
|
20
|
960L/Min
|
||||
|
-8
|
40
|
1920L/Min
|
||||
|
-10
|
60
|
2880L/Min
|
||||
|
-15
|
110
|
5280L/Min
|
||||
|
-20
|
190
|
9120L/Min
|
||||
|
-25
|
300
|
10000L/Min
|
||||
|
-32
|
400
|
19200L/Min
|
≥25dB
|
|||
|
-40
|
650
|
31200L/Min
|
||||
|
-55
|
700
|
33600L/Min
|
||||
Dimension of Pneumatic Silencer Muffler:
|
Model No
|
M
|
L1
|
L
|
S
|
|
C-6
|
G1/8''
|
7
|
33
|
13
|
|
C-8
|
G1/4''
|
8
|
38
|
14
|
|
C-10
|
G3/8''
|
10
|
43
|
17
|
|
C-15
|
G1/2''
|
11
|
49
|
22
|
|
C-20
|
G3/4'
|
14
|
60
|
27
|
|
C-25
|
G1''
|
14
|
70
|
34
|
