AC110V DC24V 1/4'' 1/8'' Inch Thread 3 Way 6014 Brass Solenoid Valve

AC110V DC24V 1/4'' 1/8'' Inch Thread 3 Way 6014 Brass Solenoid Valve

  • AC110V DC24V 1/4'' 1/8'' Inch Thread 3 Way 6014 Brass Solenoid Valve
  • AC110V DC24V 1/4'' 1/8'' Inch Thread 3 Way 6014 Brass Solenoid Valve
AC110V DC24V 1/4'' 1/8'' Inch Thread 3 Way 6014 Brass Solenoid Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 6014
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: 6014 Solenoid Valve Working Fluids: Compressed Air, Natural Gas, Water, Hydraulic Oil, Vaccum
Port Size: 1/8'', 1/4'' Orifice Size: 1 To 2.5mm
Operation: Plunger Direct Acting Voltages: 24VDC, 110VAC, 115VAC, 220VAC, 230VAC
Operation Mode: 3/2 Way, Normally Closed Body Material: Brass
Seal Material: NBR, VITON, EPDM Pressure Range: 0 To 1.6MPa
Fluid Temperature: -10°C To +80°C (NBR)
High Light:

3 Way Brass Solenoid Valve

,

6014 Brass Solenoid Valve

,

6014 Plunger Solenoid Valve

AC110V DC24V 1/4'' 1/8'' Inch Thread 3 Way 6014 Brass Solenoid Valve



The Type 6014 is a direct-acting solenoid valve system with a brass body. For neutral gases and liquids such as compressed air, natural gas, water and hydraulic oil & Technical vacuum.



1. Port Connection: 1/8'', 1/4'', sub-base
2. Body Material: Brass
3. Seal Material: NBR, FKM, PTFE, EPDM
4. Pressure: 0 to 16 Bar
5. Media temperature ranges covering -10°C to +150°C





Bottom plate installation
When installing the bottom plate, please pay attention to the allowable load cycle (5W type 100% continuous work, 8W type 60% intermittent work). The pressure port of the bottom plate is marked P (R), and the output port is marked A (B). Only ports with the same function can be connected together.
If the working pressure is consistent with the label, the 6013 type two-position two-way valve can be installed on the same base plate with the 6014 type two-position three-way valve with circuit function C (not D or T!). Under the premise of considering the function of the valve, the base plate can also be expanded. Several bottom plates can be connected together with the O-shaped connecting clip connected to the pressure port P(R).
Note! The unused, open valve port must be sealed with a cover plate (see accessories).



Main Dimension of 6014 Solenoid Valve:

AC110V DC24V 1/4'' 1/8'' Inch Thread 3 Way 6014 Brass Solenoid Valve 0


Technical Data of 6014 Solenoid Valve:

Model

Orifice Size

(mm)

Port Size

Environment Temperature

(℃)

Medium Temperature

(℃)

Working Pressure

(MPa)

CV
6014-01-B 1 Sub-base -20 to +55

NBR: -5 to +80℃

EPDM: -5 to +120℃

VITON: -10 to +150℃

0 to 1.6 0.08
6014-015-B 1.5 0 to 1 0.13
6014-02-B 2 0 to 0.8 0.13
6014-025-B 2.5 0 to 0.6 0.18
6014-01-06 1 1/8'' 0 to 1.6 0.08
6014-015-06 1.5 0 to 1 0.13
6014-02-06 2 0 to 0.8 0.13
6014-025-06 2.5 0 to 0.6 0.18
6014-01-08 1 1/4'' 0 to 1.6 0.08
6014-015-08 1.5 0 to 1 0.13
6014-02-08 2 0 to 0.8 0.13
6014-025-08 2.5 0 to 0.6 0.18


Valve 6014 is a direct-acting plunger valve. The stopper and plunger guide tube are welded together to enhance pressure resistance and leak-tightness. Various seal material combinations are available depending on the application. The coils are moulded with polyamide or with chemically resistant epoxy. In combination with a plug in accordance with DIN EN 175301-803 Form A, the valves satisfy protection class IP65.



1. Direct-acting and compact valve up to diameter of DN 2.5
2. Vibration-proof, bolted coil system
3. Increased leak-tightness with welded plunger guide tube
4. Energy-saving pulse versions


Brando Factory Production of Brass Solenoid Valves:

AC110V DC24V 1/4'' 1/8'' Inch Thread 3 Way 6014 Brass Solenoid Valve 1


More Solenoid Valves for you to choose:

AC110V DC24V 1/4'' 1/8'' Inch Thread 3 Way 6014 Brass Solenoid Valve 2AC110V DC24V 1/4'' 1/8'' Inch Thread 3 Way 6014 Brass Solenoid Valve 3AC110V DC24V 1/4'' 1/8'' Inch Thread 3 Way 6014 Brass Solenoid Valve 4AC110V DC24V 1/4'' 1/8'' Inch Thread 3 Way 6014 Brass Solenoid Valve 5



As a solenoid valve supplier, BRANDO supplys general purpose solenoid valve for general mediums control. Such as water, air, gas, oil. Offering the cost-effective solution for your projects. Available in brass, stainless steel and PVC material for your projects.


● Size Range: 1/4" to 2" (1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4")
● Voltage: 12 Volt DC, 24 Volt DC, 24 Volt AC, 110 Volt AC, 220 Volt AC
● Pressure: 0-10 bar / 0.3-16 bar
● Temperature: -10℃~180℃
● Material: Brass, Stainless Steel and PVC
● Structure: Direct Acting / Diaphragm / Pilot Operated
● Function: Normally Closed / Normally Open
● Connection Type: Threaded, Flanged, Tri Clamp
● Tolerance: ±10%
