1-1/2'' Inch Threaded UW-40 2W400-40 2/2 Way NC Brass Solenoid Valve

1-1/2'' Inch Threaded UW-40 2W400-40 2/2 Way NC Brass Solenoid Valve

The 2W400-40 solenoid valve is brass valves two-way, semi-direct lift valve that operates in a normally closed position.This means that there are two ports in which the medium flows and the valve will open to allow the medium to pass when the coil is energized. 2 / 2 Way G1-1/2 Inch Normal Close Type Operated Brass Solenoid Valve 2W400-40.High quality electric solenoid valve, for water, air or oil. It's applicable in many fields.

Direct Acting

When the solenoid is energized, the core directly opens the orifice of a Normally Closed valve. The valve will operate at pressures from 0 psi to its rated maximum. The force needed to open the valve is proportional to the orifice size and fluid pressure. As orifice size increases, so does the required force. To open larger orifices without increasing solenoid size, internal pilots are used.

Normally Closed (NC)
Fluid is shut off when the coil is de-energized, flows through the valve when the coil is energized.

Technical Data of 2W & 2S Solenoid Valve:

Main dimension of 2W & 2S Series Solenoid Valves:

Main Part OF 2W Solenoid Valve and its Material:

Main Body: Brass

Coil: Special Copper Wire

Core: Stainless Steel

Tube: Stainless Steel

Spring: Stainless Steel

Plug: NBR, Viton, Silicon

Diaphragm: NBR, Viton, Silicon
