Type 6013 2/2 Way NC Direct Acting Air Compressor Solenoid Valve

Type 6013 2/2 Way NC Direct Acting Air Compressor Solenoid Valve

Burkert type normally closed 6013 solenoid valve is a 2/2 direct-acting plunger solenoid valve. Used directly with brass body. Suitable for neutral gases and liquids such as compressed air, natural gas, water, hydraulic oil and technical vacuum. The modular design allows the sleeve body to be used as a single valve, mount the flange body on a manifold, and integrate the valve seat into a custom terminal body. Custom modifications to the valve body and sealing materials, as well as special electrical connections, provide customers with unparalleled added value in this application.


Main Dimension of 6013 Solenoid Valve:

Technical Data of 6013 Solenoid Valve:

Valve 6013 is a direct-acting plunger valve, that operates without a differential pressure over the valve. The stopper and plunger guide tube are welded together to enhance pressure resistance and leak-tightness. It can be used for low pressure applications, but also has versions that operate up to 25 bars. Various seal material combinations are available depending on the application. The coils are moulded with polyamide or with chemically resistant epoxy. In combination with a plug in accordance with DIN EN 175301-803 Form A, the valves satisfy protection class IP65.

1. Direct-acting and compact valve up to diameter of DN 6.0
2. Vibration-proof, bolted coil system
3. Increased leak-tightness with welded plunger guide tube
4. Energy-saving pulse versions

Brando Factory Production of Brass Solenoid Valves:



More Solenoid Valves for you to choose:



As a solenoid valve supplier, BRANDO supplys general purpose solenoid valve for general mediums control. Such as water, air, gas, oil. Offering the cost-effective solution for your projects. Available in brass, stainless steel and PVC material for your projects.

● Size Range: 1/4" to 2" (1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4")
● Voltage: 12 Volt DC, 24 Volt DC, 24 Volt AC, 110 Volt AC, 220 Volt AC
● Pressure: 0-10 bar / 0.3-16 bar
● Temperature: -10℃~180℃
● Material: Brass, Stainless Steel and PVC
● Structure: Direct Acting / Diaphragm / Pilot Operated
● Function: Normally Closed / Normally Open
● Connection Type: Threaded, Flanged, Tri Clamp
● Tolerance: ±10%

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
