Name: 1-1/2'' Inch UW-40 2W400-40 Pilot Diaphragm Brass Solenoid Valve
Brand: Brando
SKU: 2W400-40
Rating: 4.9 (176 reviews)

Home Products Brass Solenoid Valve

1-1/2'' Inch UW-40 2W400-40 Pilot Diaphragm Brass Solenoid Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	2W400-40

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Valve Series:	2W Series	Ref. Number:	UNI-D Type UW-40
Voltage:	AC110V AV220V DC24V	Action:	Pilot Diaphragm Drive
Port Size:	1-1/2' Inch	Media:	Water Air Gas
Fluid Viscossity:	Below 20 CST	Power:	Solenoid
Body Material:	Brass	Diaphragm Material:	NBR, FKM And EPDM
High Light:	UW-40 Brass Solenoid Valve , 2W400-40 Brass Solenoid Valve , Uni-D Type UW-40

1-1/2'' Inch UW-40 2W400-40 Pilot Diaphragm Brass Solenoid Valve

The 2W400-40 solenoid valve is brass valves two-way, semi-direct lift valve that operates in a normally closed position.This means that there are two ports in which the medium flows and the valve will open to allow the medium to pass when the coil is energized. 2 / 2 Way G1-1/2 Inch Normal Close Type Operated Brass Solenoid Valve 2W400-40.High quality electric solenoid valve, for water, air or oil. It's applicable in many fields.

Direct Acting

When the solenoid is energized, the core directly opens the orifice of a Normally Closed valve. The valve will operate at pressures from 0 psi to its rated maximum. The force needed to open the valve is proportional to the orifice size and fluid pressure. As orifice size increases, so does the required force. To open larger orifices without increasing solenoid size, internal pilots are used.

Normally Closed (NC)
Fluid is shut off when the coil is de-energized, flows through the valve when the coil is energized.

Technical Data of 2W & 2S Solenoid Valve:

2W Series	2W025-08	2W040-10	2W160-15	2W200-20	2W250-25	2W350-35	2W400-40	2W500-50
2S Series	2S025-08	2S040-10	2S160-15	2S200-20	2S250-25	2S350-35	2S400-40	2S500-50
Orifice Size	2.5	4	15	20	25	35	40	50
Port Size	1/4''	3/8''	1/2''	3/4''	1''	1-1/4''	1-1/2''	2''
Medium	Water, Air, Gas, Oil
Action	Direct Acting		Semi-Direct Diaphragm Operated
Function	2 Way, Normally Closed
Fluid Viscosity	20 CST below
Pressure Range	0 to 1.0 Mpa
Temp. Range	-5 to +85℃

Main dimension of 2W & 2S Series Solenoid Valves:
1-1/2'' Inch UW-40 2W400-40 Pilot Diaphragm Brass Solenoid Valve 0

2S Series	2W Series	A	B	C	D	E
2S025-06	2W025-06	64.5	30	75	43	1/8''
2S025-08	2W025-08	64.5	30	75	43	1/4''
2S040-10	2W040-10	70.6	32	82.4	53	3/8''
2S160-10	2W160-10	101.5	57	117	69	3/8''
2S160-15	2W160-15	101.5	57	117	69	1/2''
2S200-20	2W200-20	107	57	123.5	73	3/4''
2S250-25	2W250-25	111.5	73.5	134.5	99	1''
2S350-35	2W350-35	142	95	172	123	1-1/4''
2S400-40	2W400-40	142	95	172	123	1-1/2''
2S500-50	2W500-50	172	123	209	168	2''

Main Part OF 2W Solenoid Valve and its Material:

Main Body: Brass

Coil: Special Copper Wire

Core: Stainless Steel

Tube: Stainless Steel

Spring: Stainless Steel

Plug: NBR, Viton, Silicon

Diaphragm: NBR, Viton, Silicon
