| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | BCKH-3F-Z |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PVC bag, then inner box, then carton, then pallet |
| Delivery Time: | 1 week after payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Hose Fittings | Type: | Male Banjo |
|---|---|---|---|
| Tube OD (Inch): | 1/8", 1/4", 3/8", 1/2" | Tube OD (Mertric): | 4mm, 6mm, 8mm, 10mm, 12mm |
| Material: | Brass | Working Pressure Range: | 0 To 1.0MPa |
| Working Temperature: | -10 To +80℃ | Connection: | Push On |
| High Light: | Push To Connect Air Line Fittings,Pneumatic Push In Fittings,Push Lock Air Fittings |
||
Double Male Banjo Push To Connect Air Line Fittings 1/8'' 1/4'' 6mm 8mm
Pneumatic push-in fittings provide secure leak-free connectivity between pneumatic system components. Pneumatic push-in fittings come with a technopolymer release mechanism that allows for a quick connect and disconnect between the pneumatic tube and the fitting enabling easy construction of pneumatic systems.
Full nickel plated brass push in fittings, also called brass push to connect fittings, made of forged brass (elbows, tees, banjos, union Y and cross), are suitable for typical applications include systems for pneumatic control, robotics, instrumentation, chemicals, anti-spatter or die temperature control. Accept metric and inch tube, and PT (R, BSPT), NPT thread. Working pressure up to 1 MPa, working temperature from -10°C to +80°C.
Technical data of Pneumatic Hose Fittings:
Specifications of Double Male Banjo Brass Pneumatic Hose Fittings:
|
Model No
|
D
|
M
|
L1
|
L
|
L'
|
S
|
|
BCKH-3F-Z2.5
|
4
|
M8X1
|
7
|
26
|
45
|
12
|
|
BCKH-3F-Z4
|
6
|
M10X1
|
7
|
28
|
45
|
14
|
|
6
|
G1/8''
|
7
|
28
|
45
|
14
|
|
|
BCKH-3F-Z6
|
8
|
M12X1.25
|
9
|
29
|
52
|
17
|
|
8
|
G1/4''
|
9
|
29
|
52
|
17
|
|
|
BCKH-3F-Z8
|
10
|
M12X1.25
|
9
|
30
|
52
|
17
|
|
10
|
G1/4''
|
9
|
30
|
52
|
17
|
|
|
BCKH-3F-Z10
|
12
|
M16X1.5
|
10
|
32
|
57
|
24
|
|
12
|
G3/8''
|
10
|
32
|
57
|
24
|
Product Video of BRANDO Brass Pneumatic Hose Fittings:
List of All Push To Connect Brass Pneumatic Hose Fittings:
Choosing the Right Fittings for Your Pneumatic System:
Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.
Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting
