| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | BCKH-3U-Z |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PVC bag, then inner box, then carton, then pallet |
| Delivery Time: | 1 week after payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Hose Fittings | Type: | Male Y |
|---|---|---|---|
| Tube OD (Inch): | 1/8", 1/4", 3/8", 1/2" | Tube OD (Mertric): | 4mm, 6mm, 8mm, 10mm, 12mm |
| Material: | Brass | Working Pressure Range: | 0 To 0.8MPa |
| Working Temperature: | 0 To +60℃ | Connection: | Push On |
| High Light: | Pneumatic Quick Connect Coupling Brass,Quick Connect Coupling 1/4'',Pneumatic Air Coupling |
||
Male Y Brass Pneumatic Quick Connect Coupling 1/8'' 1/4'' 3/8'' 1/2''
Pneumatic push in fittings, also called push to connect fittings, provide a leak-free means of easily connecting hoses in your compressed air system. Fittings can have between 1-6 inlet/outlet ports or may have additional functionality such as an integrated pressure gauge or silencer.
The greatest advantage of push in fittings is the quick release system which allows for simple and easy installation by hand, eliminating the need for tools and adhesive. Due to the ease of connecting and disconnecting air lines, it allows for frequent changing of air lines at a low cost. They are offered in a wide range of tube sizes, connections, and thread combinations to suit the desired outcome.
Technical data of Pneumatic Hose Fittings:
Specifications of Male Y Brass Pneumatic Hose Fittings:
|
Model No
|
D
|
M
|
L1
|
L2
|
L
|
E
|
S
|
|
BCKH-3U-Z2.5
|
4
|
M5X0.8
|
6
|
4
|
39
|
12
|
10
|
|
BCKH-3U-Z4
|
6
|
M8X1
|
7
|
4
|
41
|
12
|
|
|
M10X1
|
7
|
4
|
42
|
13
|
|||
|
G1/8''
|
6
|
4
|
41
|
12
|
|||
|
G1/4''
|
8
|
5
|
43
|
14
|
|||
|
G3/8''
|
6
|
4
|
41
|
17
|
|||
|
G1/2''
|
8
|
5
|
43
|
22
|
|||
|
BCKH-3U-Z6
|
8
|
M10X1
|
7
|
4
|
44
|
14
|
13
|
|
G1/8''
|
6
|
5
|
43
|
12
|
|||
|
G1/4''
|
8
|
5
|
45
|
14
|
|||
|
G3/8''
|
9
|
5
|
47
|
17
|
|||
|
G1/2''
|
10
|
5
|
48
|
22
|
|||
|
BCKH-3U-Z8
|
10
|
M12X1.25
|
9
|
5
|
49
|
17
|
15
|
|
G1/8''
|
6
|
5
|
46
|
14
|
|||
|
G1/4''
|
8
|
5
|
48
|
14
|
|||
|
G3/8''
|
9
|
5
|
50
|
17
|
|||
|
G1/2''
|
10
|
6
|
51
|
22
|
|||
|
BCKH-3U-Z10
|
12
|
M16X1.5
|
10
|
5
|
53
|
19
|
19
|
|
G1/8''
|
6
|
5
|
48
|
16
|
|||
|
G1/4''
|
8
|
5
|
50
|
16
|
|||
|
G3/8''
|
9
|
5
|
52
|
17
|
|||
|
G1/2''
|
10
|
6
|
53
|
22
|
Product Video of BRANDO Brass Pneumatic Hose Fittings:
List of All Push To Connect Brass Pneumatic Hose Fittings:
Choosing the Right Fittings for Your Pneumatic System:
Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.
Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
