| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | PCF |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PVC bag, then inner box, then carton, then pallet |
| Delivery Time: | 1 week after payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Hose Fittings | Type: | Female Straight |
|---|---|---|---|
| Tube OD (Inch): | 1/8", 1/4", 3/8", 1/2" | Tube OD (Mertric): | 4mm, 6mm, 8mm, 10mm, 12mm |
| Color: | Blue, Black, Gray | Material: | Plastic |
| Working Pressure Range: | 0 To 0.8MPa | Working Temperature Range: | 0 To +60℃ |
| High Light: | Push Fit Pneumatic Hose Fittings,1/4'' Pneumatic Hose Fittings,Pneumatic Push To Connect Fittings |
||
PCF Female Straight Push Fit Pneumatic Hose Fittings 1/8'' 1/4'' 3/8'' 1/2''
Common technical parameters and features of pneumatic hose fittings:
1. Retain tightness automatically after inserting the hose.
2. Body made of high-quality polyamide (PA 66) and nickel-plated brass.
3. Seals: NBR.
4. Working temperature from 0°C up to 60°C.
5. Working pressure from 0 to 8 bar.
6. Fittings with external thread have a sealing layer, so you don't need to use any adhesives.
7. Perfect for polyethylene, polyamide, and hoses.
Technical data of Pneumatic Hose Fittings:
Specifications of PCF Female Straight Pneumatic Hose Fittings:
List of All Push To Connect Pneumatic Hose Fittings:
Choosing the Right Fittings for Your Pneumatic System:
Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.
Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
