6013 Normally Closed Direct Acting Plunger Solenoid Valve

6013 Normally Closed Direct Acting Plunger Solenoid Valve

  • 6013 Normally Closed Direct Acting Plunger Solenoid Valve
6013 Normally Closed Direct Acting Plunger Solenoid Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 6013
Payment & Shipping Terms:
Minimum Order Quantity: 5 pcs
Price: $27 to $ 40 per pc
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: 6013 Solenoid Valve Working Fluids: Compressed Air, Natural Gas, Water, Hydraulic Oil, Vaccum
Port Size: 1/8'', 1/4'' Orifice Size: 1.5, 2, 3, 4
Operation: Plunger Direct Acting Voltages: 24VDC, 110VAC, 115VAC, 220VAC, 230VAC
Operation Mode: 2/2 Way, Normally Closed Body Material: Brass
Seal Material: NBR, VITON, EPDM Pressure Range: 0 To 2.5MPa
Fluid Temperature: -10°C To +80°C (NBR)
High Light:

6013 Plunger Solenoid Valve

,

Direct Acting Plunger Solenoid Valve

,

Type 6013 Fluid Control Valve

6013 Normally Closed Direct Acting Plunger Solenoid Valve



Features of 6013 Brass Solenoid Valve:

1.Type 6013 is a general-purpose valve used for shut-off, filling, dosing and ventilation.
2.The compact valve is suitable for small flow rates, the nominal diameter lies between 2 and 6 mm.
3.The maximum pressure varies from 0.75 up to 25 bars, depending on the orifice size and coil. Because of the direct acting design, the valve can be used in systems without a pressure differential, such as a closed circulating circuit or gravity fed system. It can even be used for technical vacuum.
4.The bolted-coil design is designed to withstand strong vibrations. Housing materials are brass or stainless steel (grade 303).
5.The valve is available with an inline design with port sizes from G1/8” up to G3/8” or a subbase design suitable for manifold mounting (SFB).




Main Dimension of 6013 Solenoid Valve:
6013 Normally Closed Direct Acting Plunger Solenoid Valve 0
Technical Data of 6013 Solenoid Valve:

Model

Orifice Size

(mm)

Port Size

Working Pressure

(MPa)

KV

(m³/h)

Environment Temperature Medium Temperature Power
6013-01 1.5 1/8'' or 1/4'' 0 to 2.5 0.1 -10 to +55℃

NBR: -5 to +80℃

EPDM: -5 to +120℃

VITON: -10 to +150℃

AC: 24VA (inrush)

17VA (hold) ,

DC: 13W

6013-02 2.0 0 to 1.5 0.15
6013-03 3.0 0 to 1.0 0.31
6013-04 4.0 0 to 0.4 0.54



Valve 6013 is a direct-acting plunger valve, that operates without a differential pressure over the valve. The stopper and plunger guide tube are welded together to enhance pressure resistance and leak-tightness. It can be used for low pressure applications, but also has versions that operate up to 25 bars. Various seal material combinations are available depending on the application. The coils are moulded with polyamide or with chemically resistant epoxy. In combination with a plug in accordance with DIN EN 175301-803 Form A, the valves satisfy protection class IP65.

1. Direct-acting and compact valve up to diameter of DN 6.0
2. Vibration-proof, bolted coil system
3. Increased leak-tightness with welded plunger guide tube
4. Energy-saving pulse versions


Brando Factory Production of Brass Solenoid Valves:



6013 Normally Closed Direct Acting Plunger Solenoid Valve 1

More Solenoid Valves for you to choose:
6013 Normally Closed Direct Acting Plunger Solenoid Valve 26013 Normally Closed Direct Acting Plunger Solenoid Valve 36013 Normally Closed Direct Acting Plunger Solenoid Valve 46013 Normally Closed Direct Acting Plunger Solenoid Valve 5




As a solenoid valve supplier, BRANDO supplys general purpose solenoid valve for general mediums control. Such as water, air, gas, oil. Offering the cost-effective solution for your projects. Available in brass, stainless steel and PVC material for your projects.


● Size Range: 1/4" to 2" (1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4")
● Voltage: 12 Volt DC, 24 Volt DC, 24 Volt AC, 110 Volt AC, 220 Volt AC
● Pressure: 0-10 bar / 0.3-16 bar
● Temperature: -10℃~180℃
● Material: Brass, Stainless Steel and PVC
● Structure: Direct Acting / Diaphragm / Pilot Operated
● Function: Normally Closed / Normally Open
● Connection Type: Threaded, Flanged, Tri Clamp
● Tolerance: ±10%
