PTF Female Branch Tee Pneumatic Air Fittings 1/8'' 1/4'' 3/8'' 1/2''

PTF Female Branch Tee Pneumatic Air Fittings 1/8'' 1/4'' 3/8'' 1/2''

PTF Female Branch Tee Pneumatic Air Fittings 1/8'' 1/4'' 3/8'' 1/2''
video
PTF Female Branch Tee Pneumatic Air Fittings 1/8'' 1/4'' 3/8'' 1/2''
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: PTF
Payment & Shipping Terms:
Minimum Order Quantity: 5 pcs
Price: Negotiation
Packaging Details: PVC bag, then inner box, then carton, then pallet
Delivery Time: 1 week after payment
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 10000000pcs per month
Contact Now
Detailed Product Description
Product Name: Pneumatic Hose Fittings Type: Female Branch Tee
Tube OD (Inch): 1/8", 1/4", 3/8", 1/2" Tube OD (Mertric): 4mm, 6mm, 8mm, 10mm, 12mm
Color: Blue, Black, Gray Material: Plastic, Brass
Working Pressure Range: 0 To 0.8MPa Working Temperature Range: 0 To +60℃
High Light:

1/4'' Pneumatic Air Fittings

,

Pneumatic Air Tube Fittings

,

Pneumatic T Fitting

PTF Female Branch Tee Pneumatic Air Fittings 1/8'' 1/4'' 3/8'' 1/2''



BRANDO provides a complete line of composite push to connect fittings, including both inch and metric sizes. We have a large stock of products in our warehouse, ready to be shipped out same-day! BRANDO is your source for pneumatic connectors, branch tees, bulkhead fittings, control valves, unions, elbows, angles and manifolds.



BRANDO's Pneumatic Hose Fittings Features:



1. Optional shapes of release sleeve: As a manufacturer, BRANDO can provide Oval and Round Release Sleeve.

2. Multiple colors of release sleeve: Blue, Black, Orange, Red, Gray

3. Accommodate kinds of connection thread type: R (PT, BSPT), G (BSPP), NPT, UNF, UNC, Metric.

4. Accommodate metric size tubing OD: 3mm, 4mm, 6mm, 8mm, 10mm, 12mm, 16mm.

5. Accommodate inch size tubing OD: 1/8", 5/32", 3/16", 1/4", 5/16", 3/8", 1/2", 5/8".



Technical data of Pneumatic Hose Fittings:

Material
Plastic / Brass
Threaded Connection
BSP
BSPP
Metric Thread
NPT
Working Pressure
0 to 0.8MPa
Connecting Tube
PA
PU
Connecting Diameter Tube
3mm, 4mm, 6mm, 8mm, 10mm, 12mm, 16mm (Outer Diameter)
Medium
Compressed Air
Working Temperature
~60℃



Specifications of PTF Female Branch Tee Pneumatic Hose Fittings:

                                             PTF Female Branch Tee Pneumatic Air Fittings 1/8'' 1/4'' 3/8'' 1/2'' 0

Model No
M
φD
φD1
L1
L
L'
S
PTF4
M5X0.8
4
11
6
19
23
10
M6X1
6
23
10
G1/8''
7
24
13
G1/4''
8
25
16
G3/8''
9
26
19
G1/2''
10
27
24
PTF6
M5X0.8
6
13
6
20
24
12
M6X1
6
24
12
G1/8''
7
25
13
G1/4''
8
26
16
G3/8''
9
27
19
G1/2''
10
28
24
PTF8
G1/8''
8
15
7
23
27
15
G1/4''
8
28
16
G3/8''
9
29
19
G1/2''
10
31
24
PTF10
G1/8''
10
17
7
27
31
17
G1/4''
8
32
17
G3/8''
9
33
19
G1/2''
10
35
24
PTF12
G1/8''
12
21
7
30
33
19
G1/4''
8
34
19
G3/8''
9
35
19
G1/2''
10
37
24


List of All Push To Connect Pneumatic Hose Fittings:

PL Male 90 Degree Elbow Pneumatic Hose Fittings 1/8'' 1/4'' 3/8'' 1/2'' 1



Choosing the Right Fittings for Your Pneumatic System:



Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.

Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting



Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
