Union Cross Push To Quick Connect Pneumatic Hose Fittings 1/4'' 8mm

Union Cross Push To Quick Connect Pneumatic Hose Fittings 1/4'' 8mm

Pneumatic Hose Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.

Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting

Dimension & Order Code of Pneumatic Hose Fittings:

Union Straight Fitting:

Picture	Dimension	Part No.	D	D1	L
		PUC4	4	11	33
		PUC6	6	13	34
		PUC8	8	14	39
		PUC10	10	18	46
		PUC12	12	21	47

Union Elbow Fitting:

Picture	Dimension	Part No.	D	D1	L
		PUL4	4	11	19
		PUL6	6	13	20
		PUL8	8	14	23
		PUL10	10	18	27
		PUL12	12	21	30

Union Tee Fitting:

Picture	Dimension	Part No.	D	D1	L
		PUT4	4	11	19
		PUT6	6	13	20
		PUT8	8	14	23
		PUT10	10	18	27
		PUT12	12	21	30

Picture	Dimension	Part No.	D	D1	L
		PY4	4	11	37
		PY6	6	13	40
		PY8	8	14	41
		PY10	10	18	49
		PY12	12	21	53

List of All Plastic Pneumatic Hose Fittings:

Choosing the Right Fittings for Your Pneumatic System:

Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.

Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
