Name: Reverse Osmosis Pure System Inlet Feed Water RO Solenoid Valve 1/4'' 24V
Brand: Brando
SKU: BPV05
Rating: 4.8 (114 reviews)

Home Products RO Solenoid Valve

Reverse Osmosis Pure System Inlet Feed Water RO Solenoid Valve 1/4'' 24V

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	Brando
Certification:	CE, ISO9001
Model Number:	BPV05

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	Negotiation
Packaging Details:	Inner box, then loaded into carton, then packed by pallet for sea shipment
Delivery Time:	7 working days after receive payment
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	200000pcs per month

Contact Now

Detailed Product Description

Product Name:	RO Solenoid Valve	Operation:	Direct Acting
Orifice Size:	1 To 5mm	Port Size:	1/8'', 1/4'', 3/8''
Connection:	Female Thread, Push In Fast Fit	Body Material:	PP, POM
Medium:	Water, Air, Oil	Working Pressure:	0 To 120psi
Seal Material:	NBR, FKM, EPDM	Voltage:	12VDC, 24VDC, 36VDC, 48VDC
High Light:	Inlet Feed Water RO Solenoid Valve , RO Solenoid Valve 24V , Solenoid Valve For RO

Reverse Osmosis Pure System Inlet Feed Water RO Solenoid Valve 1/4'' 24V

Assisted by a hard-working team of professionals, we are engrossed in manufacturing, exporting and supplying RO Solenoid Valves. These valves are used in water purifier for switched on and off. The offered valves are manufactured using outstanding quality basic materials with the aid of innovative techniques under our experts' supervision. Furthermore, we provide these RO Solenoid Valves at rock bottom prices to our valued patrons.

Features:

* Easy installation

* Compact size

* Rugged design

* Accurate dimension

Dimension & Data of RO Solenoid Valves:

Reverse Osmosis Pure System Inlet Feed Water RO Solenoid Valve 1/4'' 24V 0

Model	BPV09
Medium	Water, Air, Oil, etc
Medium Temperature Range	-10 to +80℃
Body Material	PP, POM
Working Pressure Range	0-8bar
Conection Type	Female Thread
Port Size	1/4'' NPT
Voltage	12VDC, 24VDC, 36VDC, 48VDC
Seal Material	NBR, FKM, EPDM

Reverse Osmosis Pure System Inlet Feed Water RO Solenoid Valve 1/4'' 24V 1

Model	BPV05
Medium	Water, Air, Oil, etc
Medium Temperature Range	-10 to +80℃
Body Material	PP, POM
Working Pressure Range	0-8bar
Conection Type	Fast Fitting, Tube OD 6.35mm
Voltage	12VDC, 24VDC, 36VDC, 48VDC
Seal Material	NBR, FKM, EPDM

Install and Use Attentions:

1. The water solenoid valve selects the corresponding voltage and temperature according to the actual situation when selecting type.
2. When install the solenoid valve, medium flow diretion must be consistent with the direction arrow as shown in the valve body, the valve must be installed in horizontal pipe runs. Solenoid valve coil keep in a vertical position, the valve can not be put in places with splashing water or water leakage.
3. Please install a filter screen at the inlet end to avoid inhalation of impurities so that the solenoid valve can not be reset, resulting in water closes or obstructed opening.
4. If the solenoid valve is closed or blocked, please open the top four screws to clean the inner cavity impurities.
5. During use solenoid valve should be regularly cleaning dirt on the surface of the movable iron core and the piston, sealing gasket should be checked at the same time in dismounting, damaged should be replaced timely when found.
6. Before installing the solenoid valve, pipeline should be cleaned.

More RO Quick Fittings For you to choose:

Reverse Osmosis Pure System Inlet Feed Water RO Solenoid Valve 1/4'' 24V 2

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
