Name: High Temperature High Pressure Brass Solenoid Valve Type 5404 For Water Steam 230V AC 24V DC
Brand: Brando
SKU: 5404
Rating: 4.6 (105 reviews)

Home Products Brass Solenoid Valve

High Temperature High Pressure Brass Solenoid Valve Type 5404 For Water Steam 230V AC 24V DC

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	5404

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Product Name:	5404 Solenoid Valve	Working Fluids:	Neutral Mediums, Compressed Air, Water, Hydraulic Oil And Steam
Port Size:	1/4'' To 2''	Orifice Size:	13mm, 20mm, 25mm, 32mm, 40mm, 50mm
Operation:	Servo Assisted Piston	Voltages:	24VDC, 110VAC, 120VAC, 220VAC, 230VAC
Operation Mode:	2/2 Way, Normally Closed	Body Material:	Brass
Seal Material:	NBR, VITON, EPDM	Pressure Range:	0.1 To 5.0MPa
Fluid Temperature:	0°C To +180 °C
High Light:	High Temperature Solenoid Valve , Steam Solenoid Valve , Hot Water Solenoid Valve

High Temperature High Pressure Brass Solenoid Valve Type 5404 For Water Steam 230V AC 24V DC

The 5404 solenoid valve is an indirect operated solenoid valve, which means that a pressure difference of at least 1 bar is required to open the valve. The 5404 has a piston to seal the valve, instead of a flexible rubber membrane. This robust design allows for high working pressures, in some versions up to 50 bar. Gas and steam versions are also available up to 160°C. The gate sizes range from 1/4" to 1". The dimensions of the orifice range from DN 13 to DN 25. A popular application for the 5404 valve is as a relief valve for compressors.

Main Dimension of 5404 Solenoid Valve:

High Temperature High Pressure Brass Solenoid Valve Type 5404 For Water Steam 230V AC 24V DC 0

Model	G	F	H	K	L	E	B	A
5404-08	1/4''	12	40	34	65	24	97	16
5404-10	3/8''		12
5404-15	1/2''
5404-20	3/4''	16	40	60	92	45	124	20
5404-25	1''	18

Technical Data of 5404 Solenoid Valve:

Model	Orifice Size (mm)	Wokring Pressure (MPa)	Environment Temperature (℃)	Medium Temperature (℃)	KV	Power	Voltgaes
5404-08	13	0.3 to 5.0	-20 to +55	0 to +180	3.6	AC: 14VA, DC: 8W	AC: 24V, 36V, 110V, 220V, DC: 12V, 24V
5404-10
5404-15
5404-20	25	0.3 to 3.5			11
5404-25

Brando Factory Production of Brass Solenoid Valves:

High Temperature High Pressure Brass Solenoid Valve Type 5404 For Water Steam 230V AC 24V DC 1

More Solenoid Valves for you to choose:

High Temperature High Pressure Brass Solenoid Valve Type 5404 For Water Steam 230V AC 24V DC 2

As a solenoid valve supplier, BRANDO supplys general purpose solenoid valve for general mediums control. Such as water, air, gas, oil. Offering the cost-effective solution for your projects. Available in brass, stainless steel and PVC material for your projects.

● Size Range: 1/4" to 2" (1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4")
● Voltage: 12 Volt DC, 24 Volt DC, 24 Volt AC, 110 Volt AC, 220 Volt AC
● Pressure: 0-10 bar / 0.3-16 bar
● Temperature: -10℃~180℃
● Material: Brass, Stainless Steel and PVC
● Structure: Direct Acting / Diaphragm / Pilot Operated
● Function: Normally Closed / Normally Open
● Connection Type: Threaded, Flanged, Tri Clamp
● Tolerance: ±10%
