Type 5404 High Temperature Brass Solenoid Valve For Oxygen 230VAC 24VDC

Type 5404 High Temperature Brass Solenoid Valve For Oxygen 230VAC 24VDC

  • Type 5404 High Temperature Brass Solenoid Valve For Oxygen 230VAC 24VDC
Type 5404 High Temperature Brass Solenoid Valve For Oxygen 230VAC 24VDC
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 5404
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: 5404 Solenoid Valve Working Fluids: Neutral Mediums, Compressed Air, Water, Hydraulic Oil And Steam
Port Size: 1/4'' To 2'' Orifice Size: 13mm, 20mm, 25mm, 32mm, 40mm, 50mm
Operation: Servo Assisted Piston Voltages: 24VDC, 110VAC, 120VAC, 220VAC, 230VAC
Operation Mode: 2/2 Way, Normally Closed Body Material: Brass
Seal Material: NBR, VITON, EPDM Pressure Range: 0.1 To 5.0MPa
Fluid Temperature: 0°C To +180 °C
High Light:

Brass Solenoid Valve For Oxygen

,

230VAC Brass Solenoid Valve

,

24VDC Brass Solenoid Valve

Type 5404 High Temperature Brass Solenoid Valve For Oxygen 230VAC 24VDC



The 5404 solenoid valve is an indirect operated solenoid valve, which means that a pressure difference of at least 1 bar is required to open the valve. The 5404 has a piston to seal the valve, instead of a flexible rubber membrane. This robust design allows for high working pressures, in some versions up to 50 bar. Gas and steam versions are also available up to 160°C. The gate sizes range from 1/4" to 1". The dimensions of the orifice range from DN 13 to DN 25. A popular application for the 5404 valve is as a relief valve for compressors.



Main Dimension of 5404 Solenoid Valve:

Type 5404 High Temperature Brass Solenoid Valve For Oxygen 230VAC 24VDC 0

Model
G
F
H
K
L
E
B
A
5404-08
1/4''
12
40
34
65
24
97
16
5404-10
3/8''
12
5404-15
1/2''
5404-20
3/4''
16
40
60
92
45
124
20
5404-25
1''
18


Technical Data of 5404 Solenoid Valve:

Model
Orifice Size
(mm)
Wokring Pressure
(MPa)
Environment Temperature
(℃)
Medium
Temperature
(℃)
KV
Power
Voltgaes
5404-08
13
0.3 to 5.0
-20 to +55
0 to +180
3.6
AC: 14VA,
DC: 8W
AC: 24V, 36V, 110V, 220V,
DC: 12V, 24V
5404-10
5404-15
5404-20
25
0.3 to 3.5
11
5404-25

Brando Factory Production of Brass Solenoid Valves:

Type 5404 High Temperature Brass Solenoid Valve For Oxygen 230VAC 24VDC 1


More Solenoid Valves for you to choose:

Type 5404 High Temperature Brass Solenoid Valve For Oxygen 230VAC 24VDC 2Type 5404 High Temperature Brass Solenoid Valve For Oxygen 230VAC 24VDC 3Type 5404 High Temperature Brass Solenoid Valve For Oxygen 230VAC 24VDC 4



As a solenoid valve supplier, BRANDO supplys general purpose solenoid valve for general mediums control. Such as water, air, gas, oil. Offering the cost-effective solution for your projects. Available in brass, stainless steel and PVC material for your projects.


● Size Range: 1/4" to 2" (1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4")
● Voltage: 12 Volt DC, 24 Volt DC, 24 Volt AC, 110 Volt AC, 220 Volt AC
● Pressure: 0-10 bar / 0.3-16 bar
● Temperature: -10℃~180℃
● Material: Brass, Stainless Steel and PVC
● Structure: Direct Acting / Diaphragm / Pilot Operated
● Function: Normally Closed / Normally Open
● Connection Type: Threaded, Flanged, Tri Clamp
● Tolerance: ±10%
