UNI-D Type US-25 2L-25 1" High Temperature Pressure Steam Brass Solenoid Valve AC110V AC220V DC24V

UNI-D Type US-25 2L-25 1" High Temperature Pressure Steam Brass Solenoid Valve AC110V AC220V DC24V

  • UNI-D Type US-25 2L-25 1" High Temperature Pressure Steam Brass Solenoid Valve AC110V AC220V DC24V
UNI-D Type US-25 2L-25 1" High Temperature Pressure Steam Brass Solenoid Valve AC110V AC220V DC24V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 2L-25
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Temperature Of Media: High Temperature Power: Solenoid
Media: Steam, Hot Water,Oil Port Size: 1''
Structure: Servo Function: 2/2 Way Normally Closed
Operation Type: Servo Pilot Operated Valve Body Material: Brass
US Series Model Number: US-25
High Light:

High Temperature Solenoid Valve

,

Steam Solenoid Valve

,

Hot Water Solenoid Valve

UNI-D Type US-25 2L-25 1'' High Temperature Pressure Steam Brass Solenoid Valve AC110V AC220V DC24V​

Brando Supply:

US series: US-10, US-15, US-20, US-25, US-35, US-40, US-50

2L series: 2L-10, 2L-15, 2L-20, 2L-25, 2L-35, 2L-40, 2L-50



Temperature of Media:High Temperature
Power:Solenoid
Media:Steam, Hot Water, OIl
Port Size:1''
Structure:Servo
Function:2/2 Way Normally Closed
Operation Type:Servo Pilot Operated
Valve Body Material:Brass
Diaphragm Material:PTFE
Pressure Range:0.5 to 16 bar
Temperature Range:-5 to +180 ℃
Voltages:24V DC, 110V AC, 120V AC, 220V AC, 230V AC, 240V AC
US Series Model No:US-25
2L Series Model No:2L-25



Dimension of 2L/US Series Brass Solenoid Valve:

Dimension of 2L/US Series Brass Solenoid Valve:

US Series
2L Series
A
B
C
Port Size
US-10
2L-10
82
42
146
3/8''
US-15
2L-15
1/2''
US-20
2L-20
3/4''
US-25
2L-25
90
54
162
1''
US-35
2L-35
110
75
185
1 1/4''
US-40
2L-40
1 1/2''
US-50
2L-50
120
77
195
2''





Technical Data:

2L Series
2L-10
2L-15
2L-20
2L-25
2L-35
2L-40
2L-50
US Series

US-10

US-15
US-20
US-25
US-35
US-40
US-50
Orifice Size
17
17
17
22
30
30
50
Port Size
3/8''
1/2''
3/4''
1''
1-1/4''
1-1/2''

 2''

Medium
Hot Water, Oil, Steam
Action
Servo Pilot Operated
Function
2 Way, Normally Closed
Body Material
Brass, Stainless Steel
Seal Material
PTFE, FKM

Pressure Range

0.5 to 16 bar
Temp. Range
-5 to +180℃



CAUTIONS:
1. Minimum pressure to open:over 0.5~1kgf-c㎡
2. Before pipelining, the pipe line must be very clean without any contaminants or any other things not ought to be existed.
3. To prolong the life time of the product, Y-line filter should be installed in the front end of solenoid valve.
4. AC voltage tolerance:±10%;DC voltage tolerance:±1%
5. It should be installed horizontally;vertical installation is not advisable.



Not Suitalbe For Fluid As Below:
1. Liquid status when it is high temperature;solid status when it is cool.
2. Corrosive fluid
3. Viscosity over 20cst



Brando Factory Production of Brass Solenoid Valves:



UNI-D Type US-25 2L-25 1" High Temperature Pressure Steam Brass Solenoid Valve AC110V AC220V DC24V 1



Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing



Welcome to your any problem and inquiry!
