1/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V

1/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V

  • 1/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V
  • 1/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V
1/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: VMI
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: Quick Exhaust Solenoid Valve Working Fluids: Water, Air, Oil, Vaccum, Steam
Port Size: 1/8'', 1/4'' Orifice Size: 1.5 To 4.0mm
Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC, 380VAC (50/60Hz) Operation: Direct Acting
Operation Mode: 3/2 Way (Normally Closed/Normally Open) Body Material: Brass, Stainless Steel
Seal Material: NBR, VITON, EPDM Pressure Range: 0 To 13.0 Bar
Replacement Valves: 8320 Series, VX31/32/33 Series, VMI Sereis
High Light:

3 Way Brass Solenoid Valve

,

Quick Exhaust Brass Solenoid Valve

1/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V



This quick-exhaust solenoid valve features a universal valve configuration, allowing it to be connected in either a normally closed or normally open position. It is ideal for use with air, inert gases, light oil, and water, and is rated for indoor or outdoor work environments.



Technical Data of 3 Way Quick Exhaust Solenoid Valve:

1/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V 0

Model
Function
Orifice Size
Port Size
CV
Working Pressure (bar)
Medium Temperature
AC
DC
VX31
3 Way, Normally Closed
1.5
1/8'', 1/4''
(G, NPT)
0.07
13
11
NBR: -5~+85℃,
EPDM: -5~+150℃,
FKM: -10~+150℃
2.0
0.14
11
9
2.5
0.21
9
7
3.0
0.25
6
4
4.0
0.35
3.5
2
VX32
3 Way, Normally Open
1.5
0.07
13
11
2.0
0.14
11
9
2.5
0.21
9
7
3.0
0.25
6
4
4.0
0.35
3.5
2
VX33
3 Way, Universal Operation
1.5
0.07
13
11
2.0
0.14
11
9
2.5
0.21
9
7
3.0
0.25
6
4
400
0.35
3.5
2

1/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V 1


More Solenoid Valves for you to choose:

1/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V 21/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V 31/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V 41/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V 5



Brando Factory Production of Brass Solenoid Valves:

1/4'' 1/8'' 3 Way Quick Exhaust Brass Solenoid Valve 8320G174 8320G172 240V 120V 24V 6



As a solenoid valve supplier, BRANDO supplys general purpose solenoid valve for general mediums control. Such as water, air, gas, oil. Offering the cost-effective solution for your projects. Available in brass, stainless steel and PVC material for your projects.


● Size Range: 1/4" to 2" (1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4")
● Voltage: 12 Volt DC, 24 Volt DC, 24 Volt AC, 110 Volt AC, 220 Volt AC
● Pressure: 0-10 bar / 0.3-16 bar
● Temperature: -10℃~180℃
● Material: Brass, Stainless Steel and PVC
● Structure: Direct Acting / Diaphragm / Pilot Operated
● Function: Normally Closed / Normally Open
● Connection Type: Threaded, Flanged, Tri Clamp
● Tolerance: ±10%
