TPE 1261402 Diaphragm Repair Kit For 1 1/2" Norgren 8296600 Dust Collector Pulse Valve

TPE 1261402 Diaphragm Repair Kit For 1 1/2" Norgren 8296600 Dust Collector Pulse Valve

  • TPE 1261402 Diaphragm Repair Kit For 1 1/2" Norgren 8296600 Dust Collector Pulse Valve
  • TPE 1261402 Diaphragm Repair Kit For 1 1/2" Norgren 8296600 Dust Collector Pulse Valve
TPE 1261402 Diaphragm Repair Kit For 1 1/2" Norgren 8296600 Dust Collector Pulse Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 1261402
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plastic Bags, Cartons, Pallet
Delivery Time: 4-7 Days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Product Name: 1261402 Diaphragm Repair Kit Applicable Valves: 1 1/2'' 8296600
Membrane Material: TPE Mounting Hole Size: φ6.0mm
Center Distance: φ114.0mm Seat Outer Diameter: φ68.5mm
Seat Inner Diameter: φ39.0mm Air Hole: 1
Packaging: Individual Plastic Bag Sealed
High Light:

Norgren Diaphragm

,

Norgren Pulse Valve Diaphragm

,

Norgren Membrane

TPE 1261402 Diaphragm Repair Kit For 1 1/2'' Norgren 8296600 Dust Collector Pulse Valve



This 1261402 repair kit diparagm is installed on Norgren 1 1/2'' 8296600 dust collector pulse valves. This TPE diaphragm is a key component in a diaphragm pulse valve, which is designed to provide shorter pressure decay times and higher kv values. TPE material has good chemical resistance and aging resistance, can be used in a wide temperature range from -40 ℃ to 85 ℃, and its service life is 4-5 times that of similar traditional fabric diaphragms. We supply all range of diaphragm repair kits for Norgren pulse valves, if you don't know the corresponding diaphragm of the valve, pls refer to the comparison table below.



YouTube video of 1261402 Diaphragm Repair Kit For Norgren Pulse Valve:



Main dimension of 1261402 Norgren Type Diaphragm Valve Repair Kit:

TPE 1261402 Diaphragm Repair Kit For 1 1/2" Norgren 8296600 Dust Collector Pulse Valve 0



Details of Repair Kit Diaphragm For Norgren 1.5'' 8296600 Pulse Valve:

TPE 1261402 Diaphragm Repair Kit For 1 1/2" Norgren 8296600 Dust Collector Pulse Valve 1



Available Models of Diaphragm Valve Repair Kits For Norgren Pulse Valves:

Ordering Code
Fitted Valve Code
Valve Port Size
Material
1261253
8296300
3/4''
TPE
1261253
8296400
1''
TPE
1261402
8296600
1-1/2''
TPE
1268274
8296700
2''
TPE
1268274
8296800
2-1/2''
TPE
1271526
8296900
3''
TPE



Factory Production Pictures of Solenoid Valve Diaphragm Kits:

34

12



Diaphragm Features:


1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.



2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.



3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.



4. Facbric-reinforced diaphragms advantages:
* No leakage * No Lubrication * No Breakaway Force * No Friction
* Functionality Over Wide Pressure Ranges
* High Strength * Low Cost * Simple Design * Versatility



5. EPDM, Viton all available.
