2W160-15 UW-15 1/2" Semi Direct NBR Diaphragm Uni-D Type Brass Solenoid Valve 110V AC 12V DC

2W160-15 UW-15 1/2" Semi Direct NBR Diaphragm Uni-D Type Brass Solenoid Valve 110V AC 12V DC

    • 2W160-15 UW-15 1/2" Semi Direct NBR Diaphragm Uni-D Type Brass Solenoid Valve 110V AC 12V DC
    • 2W160-15 UW-15 1/2" Semi Direct NBR Diaphragm Uni-D Type Brass Solenoid Valve 110V AC 12V DC
    • 2W160-15 UW-15 1/2" Semi Direct NBR Diaphragm Uni-D Type Brass Solenoid Valve 110V AC 12V DC
    • 2W160-15 UW-15 1/2" Semi Direct NBR Diaphragm Uni-D Type Brass Solenoid Valve 110V AC 12V DC
  • 2W160-15 UW-15 1/2" Semi Direct NBR Diaphragm Uni-D Type Brass Solenoid Valve 110V AC 12V DC

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: UW-15

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: $3 to $7 per pc
    Packaging Details: Inner boxes, Cartons, Pallet
    Delivery Time: 4-7 days
    Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
    Supply Ability: 150000 pcs per month
    Contact Now
    Detailed Product Description
    Product Name: UW-15 Uni-D Type Solenoid Valve Pipe Size: 1/2 Inch
    Pipe Connection: Female Thread Body Material: Brass
    Diaphragm Material: NBR (Standard), Viton (Option) Voltages: DC12V, DC24V, AC110V, AC220V
    Orifice Size: 15mm Working Medium: Water, Air, Oil, Gas, Fuel
    Fluid Temperature: +5 To +80℃ Operating Pressure: 0 To 5 Bar

    2W160-15 UW-15 1/2'' Semi-direct NBR Diaphragm Uni-d Type Brass Solenoid Valve 110V AC 12V DC



    2W Series 2/2 Normally Closed Direct Lift Diaphragm Valves. The Valve Body is made of Brass. Standard seals is NBR, and available is VITON. The Operating pressure Range is 0 to 5 Bar (DC). Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 40 Centistokes.



    The resilience of Diaphragm allows it to seal around particulates in the fluid, making it ideal for service with Air, Inert Gas, Liquid, Vacuum. Diaphragm solenoid valves are used wherever fluid flow has to be controlled automatically. They are being used to an increasing degree in the most varied types of plants and equipment. 100% factory tested to ensure zero leakage from valves. Coils are made inhouse. Pick-up and drop-out as per standard.



    YouTube video of 1/2 Inch UW-15 Semi-direct Electric Solenoid Valve:



    Main dimension of 2W160-15 Normally Close Brass Solenoid Valve:

    2W160-15 UW-15 1/2" Semi Direct NBR Diaphragm Uni-D Type Brass Solenoid Valve 110V AC 12V DC



    Details enlargement of Semi-direct NBR Diaphragm Solenoid Valve:

    2W160-15 UW-15 1/2" Semi Direct NBR Diaphragm Uni-D Type Brass Solenoid Valve 110V AC 12V DC



    Specifications of 2W, UD & UW Series 2/2 Way NC Solenoid Valves:

    Brando No 2W025-06 2W025-08 2W040-10 2W160-10 2W160-15 2W200-20 2W250-25 2W350-35 2W400-40 2W500-50
    Reference No UD-6 UD-8 UD-10 UW-10 UW-15 UW-20 UW-25 UW-35 UW-40 UW-50
    Operating medium Air, Inert Gas, Liquid, Vacuum
    Valve type 2/2 way, normally closed (NC)
    Wetted Surface

    Valve Body: Brass

    Seals: NBR (Buna); Option: Viton (FKM)

    Armature Assembly: Stainless Steel

    Operation Direct Acting, Uni-Directional, Zero Differential
    Pipe size 1/8'' 1/4'' 3/8'' 3/8'' 1/2'' 3/4'' 1'' 1 1/4'' 1 1/2'' 2''
    Working pressure 0 to 101 PSI / 0-0.7 Mpa (for Air, Water); 0 to 72 PSI / 0-0.5 Mpa (for Oil)
    Working temperature Media: -5 to 80°C (NBR Seals), -5 to 120°C (VITON Seals); Ambient: -5 to 45°C
    Fluid viscosity Below 20cst



    Production process of Brass Body Water Air Oil Gas Fuel Solenoid Valve:

    2W160-15 UW-15 1/2" Semi Direct NBR Diaphragm Uni-D Type Brass Solenoid Valve 110V AC 12V DC



    2S & 2W series 2/2 Direct Lift Diaphragm Normally Closed Solenoid Valve:



    To open: when the valve receives an electrical signal, a magnetic field is formed which attracts the plunger covering the main orifice to lift off, causing system pressure to drop. As system pressure on the top of the diaphragm is reduced, full system pressure on the other side of the diaphragm acts to lift the diaphragm away from the main orifice, which allows media to flow through the valve. Since the bleed orifice is dimensionally smaller than the pilot orifice, the system pressure cannot rebuild on the top of the diaphragm as long as the pilot orifice remains open. When the system pressure is 0 PSI, the valve also can be operated.



    To close: when the valve is de-energized, it releases its hold on the plunger. Then the plunger forced by the spring drops and covers the main orifice. The system pressure builds up on the top of the diaphragm through the bleed orifice, forcing the diaphragm down until it covers the main orifice and stops media flow through the valve. When the system pressure is 0 PSI, the valve still can be operated.



    Focus on your demands, Offer you best solution:



    √ Contact us if some points you have doubt

    √ Contact us if somewhere need to change
    √ Contact us if not the one you are looking for

    √ Contact us if you are doing designing



    Welcome to your any question and inquiry!
