White 33bar Max.gas Tigh Test Pressure Single Pressure Control Switch

White 33bar Max.gas Tigh Test Pressure Single Pressure Control Switch

  • White 33bar Max.gas Tigh Test Pressure Single Pressure Control Switch
  • White 33bar Max.gas Tigh Test Pressure Single Pressure Control Switch
  • White 33bar Max.gas Tigh Test Pressure Single Pressure Control Switch
  • White 33bar Max.gas Tigh Test Pressure Single Pressure Control Switch
White 33bar Max.gas Tigh Test Pressure Single Pressure Control Switch
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE ISO
Model Number: MLSP530
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: negotiation
Packaging Details: Inner box, carton, then packed by pallet
Delivery Time: 10 Working Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 400000PCS PER MONTH
Contact Now
Detailed Product Description
Part Name: Single Ressure Control Pressure Switch Reset: AUTO
Max.gas Tight Test Pressure: 33 Bar Pressure Range: 8~30 Bar
Inductive Current: 72A Certification: CE, ISO
High Light:

Pressure Control Switch

,

Compressed Air Pressure Switch

White 33bar Max.gas Tigh Test Pressure Single Ressure Control



White 33bar Max.gas Tigh Test Pressure Single Ressure Control with copper air-box connector, suitable for freon, air, liquid and other non-corrosive media; with stainless steel air-box connector, it can be used with liquid ammonia etc corrosive gas or liquid system.



Introduction:
1, P series pressure controls can start and stop refrigeration compressors and fans of air condensers.

2, P series pressure controls are fitted with 3 kinds of changeover switch: a single pole double throw (SPDT), a double pole single throw(DPST) and a double pole double throw(DPDT). The position of the switch is determined by the pressure control setting and the pressure at the connector.
3, P series pressure controls can be used not only in fluoride refrigeration, but also in air and liquid.

4, P series pressure control can protect compressors in refrigeration and air-condition plant, and keep them from over-low pressure or over-high suction pressure.



Specification of Pressure Switch:



Rated Voltage(v) 125V 250V 24V
Rated Amps A.C. A.C. D.C.
Non-Inductive Current 20A 10A 10A
Inductive Current Full Load Current 15A 8A 8A
Locked Roter 72A 64A




The Structure Diagram:

White 33bar Max.gas Tigh Test Pressure Single Pressure Control Switch 0

The Drawing of the Switch



White 33bar Max.gas Tigh Test Pressure Single Pressure Control Switch 1

The Connection of the Switch



White 33bar Max.gas Tigh Test Pressure Single Pressure Control Switch 2



The Switch Contact Form



The Application of Switch:



1. MLSP Series pressure control can be used in Pneumatic, boiler, fire protection, ironing, hydraulic, pumps and other equipment.

2. MLSP Series pressure control can start and stop refrigeration compressors and fans of condensers.

3. MLSP Series pressure control used in refrigeration and compressor air system, adjust the equipment is high, low limit control and avoid the over-low suction pressure and over-high exhaust pressure.



About Service:

1. We offer professional order operation service: Same sales person follows the order from discussing step to the end of you get the goods of order

2. If any problem occur during production or you meet quality problem when you are using our goods, inform us at once, we will offer you best solution

3. Contact us via email, phone calling, skype, or other chatting methods, we will response at once



The pictures of our Pressure Switch:



White 33bar Max.gas Tigh Test Pressure Single Pressure Control Switch 3





White 33bar Max.gas Tigh Test Pressure Single Pressure Control Switch 4

We also produce other kind switch







Welcome your any question, we will response at once. We also can produce as customized.

Welcome your drawing or sample.
