0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor

0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor

  • 0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor
0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 0927200
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Port Size: 1/2'' Orifice Size: 12mm
Function: 2 Way, NC Action: Pilot Operated
Seal Material: NBR Voltages: 24VDC, 110VAC, 220VAC
Working Pressure Range: 0.07 To 1.6 MPa Application Examples: Air Compressor
High Light:

0927200 Solenoid Valve

,

1/2'' Solenoid Valve

,

Screw Air Compressor Valve

0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor



Solenoid Valves for compressed air systems:


Solenoid valves and ball valves are often used in compressed air systems. They are for example used to control actuators or the main air supply. To prevent leakage and pressure drops during the night, a solenoid valve or ball valve can be installed at the compressor output. The valve is open during the day and closed at night. The valve can be activated by for example a light switch or a timer. Solenoid valves for compressed air must have a high Kv-value to minimize the pressure drop. Indirect valves are suitable, because in general there is always sufficient pressure differential to function properly. In case of low pressures a semi-direct or direct valve may be better suited. Seal materials that can be used for compressed air are FKM (Viton), PTFE or NBR. EPDM is less suitable, because compressed air often contains oil.



Main Dimension of 0927 & 0955 Series Air Compressor Solenoid Valve:

0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 0

Model
Orifice Size
(mm)
Port Size
(Inch)
a
b
c
e
h
0927000
8
1/4''
45
31.5
22
53
97
0955105
114
0927100
10
3/8''
97
0955205
114
0927200
12
1/2''
97
0955305
114
0927300
20
3/4''
65
44
30
86
113
0955405
130
0927400
25
1''
113
0955505
130
0927500
32
1 1/4''
95
47
31
131
136
0955605
153
0927600
40
1 1/2''
136
0955705
153
0927700
50
2''
112
55
39.5
163
155
0955805
172



Technical Data of 0927 & 0955 Series Air Compressor Solenoid Valve:

Model
0927000
0927100
0927200
0927300
0927400
0927500
0927600
0927700
0955105
0955205
0955305
0955405
0955505
0955605
0955705
0955805
Orifice Size
(mm)
8
10
12
20
25
32
40
50
Port Size
(Inch)
1/4''
3/8''
1/2''
3/4''
1''
1 1/4''
1 1/2''
2''
Effective Area (mm²)
20
40
60
110
190
300
400
500
Function
2 Way, Normally Closed: (0927 series), Normally Open: (0955 series)
Action
Diaphragm Pilot Operated
Working Pressure
0.07 to 1.6 MPa
0.1 to 1.6 Mpa
Working Temp
NBR: -5 to +80℃; FKM, EPDM: -5 to +150℃
Voltages
12VDC, 24VDC, 110VAC, 220VAC



Brando Solenoid Valve Factory Production Video:



More Air Compressor Solenoid Valves for you to choose:



0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 1 0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 2 0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 3 0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 4
COMBO OPTIMUM OPTIMUM-HP 3 Way Solenoid Valve
0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 5 0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 6 0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 7 0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 8
6013 6014 6213 5404
0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 9 0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 10 0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 11 0927200 1/2'' 2 Way NC Solenoid Valve For Screw Air Compressor 12
PU225A Series 0955 Series 0927 Series 2V025-08
