Place of Origin: | China |
Brand Name: | BRANDO |
Certification: | CE, ISO |
Model Number: | C113825 |
Minimum Order Quantity: | 1 Set |
---|---|
Price: | Negotiation |
Packaging Details: | Plastic bag, Box, Carton, Pallet |
Delivery Time: | 4 to 7 working days |
Payment Terms: | L/C, T/T, PayPal, Western Union |
Supply Ability: | 100000 sets per month |
Product Name: | Pulse Valve Diaphragm | Ordering Code: | C113825, C1138-25 |
---|---|---|---|
Diaphragm Material: | NBR, FKM | 1 Set: | 1pc Diaphragm, 1pc Spring |
Fitted Pulse Valve Port Size: | 1.5'' | Fitted Pulse Valve Model: | G353A045 |
Highlight: | ASCO C113825 Diaphragm,ASCO C113825 Membrane,ASCO Pulse Jet Valve Diaphragm |
C113825 C113-825 Diaphragm For ASCO Pulse Jet Valve 1.5'' G353A045
C113825, C1138-25 Diaphragm (Membrane) for ASCO pulse valve G353A045; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse Jet Valve is a solenoid pilot operated diaphragm valve specially designed to deliver extremely fast pulsing in reverse-jet dust collector systems. With its high flow rates, higher peak pressure and the fastest response times on the market it delivers optimal filter cleaning performance, while using significantly less air. This results in energy savings for the user.
Ordering Number of Diaphragm For ASCO Pulse Valve:
Valve Port Size
|
Pulse Valve Model
|
Diaphragm Model
|
Diaphragm Material
(FKM is also available)
|
3/4''
|
SCG353A043
|
C113444
|
TPE (White), NBR (Black)
|
1''
|
SCG353A044
|
||
3/4''
|
SCG353-052
|
||
1''
|
SCG353-053
|
||
3/4''
|
SGG353A043
|
||
1''
|
SGG353A044
|
||
3/4''
|
SGG353-052
|
||
1''
|
SGG353-053
|
||
1 1/2''
|
SCG353A047
|
C113827
|
NBR
|
SGG353A065
|
|||
2''
|
SCG353A050
|
C113685, C113686
|
NBR
|
2 1/2''
|
SCG353A051
|
||
3''
|
SCXE353.060
|
C123432, C123433
|
NBR
|
SCG353D060
|
|||
3/4''
|
G3530A41
|
C113443
|
NBR
|
1''
|
G353A042
|
||
3/4''
|
G353-055
|
||
1''
|
G353-056
|
||
1 1/2''
|
G353A045
|
C113825
|
NBR
|
G353-066
|
|||
1 1/2''
|
G353A046
|
C113826
|
NBR
|
G353A063
|
|||
2''
|
G353A048
|
C113684
|
NBR
|
2 1/2''
|
G353A049
|
Main Dimension of C113825 Diaphragm:
Product Video of C113825 Membrane:
Pictures of Pulse Valve Diaphragm Production:
More Related Products For you to choose:
![]() |
![]() |
![]() |
![]() |
Threaded Type | Remote Pilot Type | Straight Through Type | Submerged Type |
![]() |
![]() |
![]() |
![]() |
Diaphragm | Solenoid Coil | Solenoid Armature | Pulse Controller |
