Name: Stainless Steel Pneumatic Angle Seat Valve Tri-Clamp 1/2'' DN15 Steam Angle Seat Valve
Brand: Ningbo Brando Hardware Co., Ltd
SKU: ASV25SSQ32-50
Price: 49.10 USD
Availability: InStock

Home Products Pneumatic Cylinder Valve

Stainless Steel Pneumatic Angle Seat Valve Tri-Clamp 1/2'' DN15 Steam Angle Seat Valve

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	ASV25SSQ32-50

Payment & Shipping Terms:

Minimum Order Quantity:	20 pcs
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,
Supply Ability:	50000 pcs per month

Contact Now

Detailed Product Description

Product Name:	Pneumatic Angle Seat Valve	Port Connection:	Tri Clamp
Port Size:	1/2''	Body Material:	Stainless Steel 304
Seal Material:	PTFE	Actuator Material:	Stainless Steel
Actuator Size:	50mm Actuator	Medium Working Pressure:	0 To 1.6 MPa
Media Temperature:	-10 To +180 ℃	Working Medium:	Neutral Liquid And Gas
Highlight:	1/2 inch Tri Clamp pneumatic angle seat valv , DN15 Tri Clamp angle seat valve , normally closed pneumatic angle seat valve

Stainless Steel Pneumatic Angle Seat Valve Tri-Clamp 1/2'' DN15 Steam Angle Seat Valve

The 1/2'' Tri-Clamp Pneumatic Steam Angle Seat Valve is a 2/2-way pneumatically actuated process valve designed for on/off control of steam, water, air, gases and compatible liquids. The Tri-Clamp connection makes it particularly suitable for sanitary or hygienic piping systems, while the angle-seat structure provides a relatively direct flow path. ASV25SSQ32-50, with a 1/2'' connection, DN15 size, 304 stainless-steel body and PTFE seal.

Typical Applications

Water treatment equipment
Compressed-air systems
Steam control
Industrial heating systems
Chemical processing
Food and beverage equipment
Pharmaceutical process equipment
High-viscosity fluid handling
General industrial automation

Technical Data:

Product Name	Pneumatic Angle Seat Valve
Port Size	1/2'' to 4''
Orifice Size	DN10 to DN100
Port Connection	Threaded, Flanged, Welded, Tri Clamp
Body Material	Stainless Steel 304, Stainless Steel 316
Seal Material	PTFE
Actuator Material	Plastic, Stainless Steel
Function	Single Acting Normally Closed Double Acting Normally Closed Double Acting Normally Open
Working Medium	Water, Air, Steam, Gas, Liquid, etc
Medium Temperature	-10 to +180℃
Ambient Temperature	-10 to +60℃
Working Pressure	0 to 1.6 MPa

Main Dimension:

1'' DN25 Tri-Clamp Air Actuated Angle Seat Valve With Pneumatic Actuator 0

Nominal Diameter	Size				Quick Connection Size	Actuator
Nominal Diameter	L	L1	L2	H	D	Actuator
15	190	131	61.5	158	50.5	φ50
20	193	130.5	61.5	166	50.5	φ50
25	214	140.5	75.5	183	50.5	φ63
32	220	150	75.5	191	50.5	φ63
40	238	180	75.5	196	64	φ63
50	256	195.5	75.5	210	64	φ80
