Shako Type 2/2 Solenoid Valve PU225A Series PU225A-04 AC220V

Shako Type 2/2 Solenoid Valve PU225A Series PU225A-04 AC220V

PU225A-04 is a 2/2-way normally closed (N.C.) brass solenoid valve from the SHAKO PU225A series. It uses a pilot-operated diaphragm structure, with a 1/2" port and 25 mm orifice, making it suitable for relatively high-flow air, water, and light-oil applications.

Working Principle

The PU225A-04 uses a pilot-operated diaphragm.

When the coil is de-energized, the main valve remains closed. When the coil is energized, the pilot mechanism changes the pressure balance across the diaphragm, allowing the 25 mm main orifice to open.

The PU225A series is specifically designed for low starting pressure, while maintaining a relatively large flow passage.

Typical Applications

PU225A-04 can be considered for:

Compressed-air systems
Water-control equipment
Light-oil systems
Industrial automation
Process pipelines
Fluid-control machinery
Compressor equipment
General industrial equipment

The manufacturer's documentation identifies compressed air, light oil and water as applicable media; seal compatibility should be checked for the specific fluid.

Main Dimension of PU225A series Solenoid Valve:

Technical Data of PU225A series Solenoid Valve:
