DMF-T-62S is a 2-1/2-inch straight-through electromagnetic pulse jet valve commonly used in dust collector reverse-pulse cleaning systems. Its inlet and outlet are arranged at 180° on the same centerline, making it different from the 90° flow path of the DMF-Z series.

How DMF-T-62S Works

DMF-T-62S is an integral-pilot solenoid valve. When the pulse controller energizes the solenoid coil, the pilot mechanism changes the pressure inside the diaphragm chamber. The resulting pressure difference opens the diaphragm and releases compressed air through the valve.

When the electrical signal ends, the pilot closes and the diaphragm returns to its sealing position.

The straight-through design keeps the inlet and outlet aligned, providing a direct airflow path for the cleaning pulse.

Main Applications

DMF-T-62S is used in reverse-pulse cleaning equipment such as:

Baghouse dust collectors
Cartridge filter systems
Envelope filters
Ceramic filter systems
Sintered-metal-fiber filters
Industrial dust extraction systems

It is also used in filtration equipment for industries such as cement, steel, power generation, chemical processing and construction.

Technical Data of  T series Straight Through Pulse Jet Valves:

Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.

Dimension of DMF-T-62S BFEC Pulse Jet Valve:

More BFEC Pulse Valve For You to Choose:

           Right Angle Type                         Quick Mount Type                         Submerged Type

            Diaphragm                     Solenoid Coil                  Armature Assembly            Pulse Controller
