CAC20T4 3/4'' GOYEN type Electromagnetic Pulse Valve Dust Collector 24V 110V 220V

CAC20T4 3/4'' GOYEN type Electromagnetic Pulse Valve Dust Collector 24V 110V 220V

A CAC20T4 is a 3/4-inch (20 mm) threaded integral pilot pulse jet diaphragm valve for dust collector systems, baghouses, and cartridge filtration units.
The "CA" designation indicates an integral solenoid pilot mounted directly on the valve, while "C" specifies a conduit connection enclosure, "20" denotes the 3/4" size, "T" stands for threaded inlet/outlet ports, and "4" indicates Goyen’s Millennium Series 4 design.

 Key Technical Specifications
Port Size & Connection: 3/4-inch (20 mm) female threaded (NPT or BSP/G) inlet and outlet ports.
Structure: Right-angle configuration (90° orientation between inlet and outlet) for single-diaphragm high-speed pulsing.
Operation: Integrally piloted solenoid operated.
Standard voltage choices include 24V DC, 24V AC, 110V/120V AC, and 220V/240V AC.
Body Material: Die-cast aluminum body and cover.
Diaphragm Material: Standard Shockwave Nitrile/Buna-N for ambient operating conditions (-40°C to 82°C / -40°F to 180°F), or Viton (FKM) for high-temperature and chemical exposure.

Common Replacement & Maintenance Parts
Diaphragm Repair Kits: Uses Goyen type 3/4" Series 4 rebuild kits:K2034 (Standard Nitrile / Shockwave)  K2033 (High-Temperature Viton)  Pilot Operator Kit: Standard pilot repair kit is K0380 (Buna) or K0384 (Viton).

​

Technical data of Right Angle Pulse Jet Valves:

CAC20T4 Dimension:

Our Production:

Solenoid Coil	Solenoid Armature	Diaphragm	Pulse Controller
