CA76T 3 Inch Right Angle Solenoid Valve K7600 K7601 Pneumatic Pulse Jet Valve

CA76T 3 Inch Right Angle Solenoid Valve K7600 K7601 Pneumatic Pulse Jet Valve

A CA76T is a 3-inch (76 mm) threaded integral pilot pulse jet diaphragm valve for large industrial reverse pulse-jet dust collection systems, baghouses, and cartridge filtration units.
The "CA" prefix indicates an integral solenoid pilot mounted directly on the valve, while the "T" suffix signifies standard threaded inlet and outlet ports.

Key Technical Specifications
Port Size & Connection: 3-inch (76 mm) threaded ports (available in NPT or BSP/G threads).
Structure: Right-angle design (90° offset between inlet and outlet) featuring a double-diaphragm setup for high-volume air delivery and ultra-fast opening/closing response.
Operation: Integrally piloted solenoid valve.
Common voltages include 24V DC, 24V AC, 110V/120V AC, and 220V/240V AC (e.g., standard models like CA76T010-300 or CA76T010-305).
Body Material: Die-cast aluminum alloy.
Diaphragm Material: Standard Nitrile/Buna-N (NBR) for normal ambient temperatures (-40°C to 82°C / -40°F to 180°F), or Viton (FKM) for high-temperature/harsh chemical service (up to 232°C / 450°F).

Common Replacement & Maintenance Parts
Diaphragm Repair Kits: Uses Goyen type 3" double-diaphragm rebuild kits, specifically model K7600 (or K7604 for high-temp Viton).

Technical data of Right Angle Pulse Jet Valves:

Dimension of CA76T Goyen Type Pulse Jet Valve:

More Goyen Type Pulse Valves for you to choose:

T Series	DD Series	FS Series	MM Series
RCA Series	Solenoid Coil	Solenoid Armature	Diaphragm
