CA62T Pulse Jet Valve 2-1/2'' CA62T CA62T011-300 CA62T010-300 CA62T010-305

CA62T Pulse Jet Valve 2-1/2'' CA62T CA62T011-300 CA62T010-300 CA62T010-305

A CA62T is a 2.5-inch (62 mm) threaded integral pilot pulse jet diaphragm valve for large-scale dust collectors, baghouses, and cartridge filtration systems.
The "CA" prefix indicates an integral solenoid pilot attached directly to the valve head, while the "T" suffix signifies standard threaded inlet and outlet ports.

Key Technical Specifications
Port Size & Connection: 2.5-inch (62 mm) threaded (NPT or BSP/G) inlet and outlet connections.
Structure: Right-angle configuration (90° orientation between inlet and outlet) with a double-diaphragm design to achieve high air delivery volume and rapid response times.
Operation: Integral solenoid pilot operated. Standard solenoid voltage options include 24V DC, 24V AC, 110V/120V AC, and 220V/240V AC (e.g., standard models CA62T010-300 or CA62T010-305).
Body Material: Die-cast aluminum alloy.
Diaphragm Material: Standard Nitrile/Buna-N for standard temperatures, or Viton (FKM) options for high-temperature and harsh chemical environments.

Replacement & Maintenance Parts
Diaphragm Repair Kits: Uses Goyen type 2.5" double-diaphragm rebuild kits, primarily model K5004 (M1638).

Technical data of Right Angle Pulse Jet Valves:

Dimension of CA62T Goyen Type Pulse Jet Valve:

Video of CA62T Goyen Type Pulse Jet Valve:

More Goyen Type Pulse Valves for you to choose:

T Series	DD Series	FS Series	MM Series
RCA Series	Solenoid Coil	Solenoid Armature	Diaphragm
