The CA20T is a 3/4-inch threaded, right-angle pulse jet valve. It is designed specifically to produce short, high-volume blasts of compressed air to clean filter bags, cartridges, or envelope filters in dust collector baghouse systems.
Key Specifications Port Size: 3/4" (DN20) female threaded inlet and outlet (BSP or NPT). Body Material: Die-cast aluminum alloy. Valve Structure: Right-angle configuration (outlet is 90° relative to the inlet). Actuation: Integral pilot solenoid coil (CA prefix indicates direct-mounted coil; RCA indicates remote air-pilot operated). Operating Pressure: 0.35 to 0.85 MPa / 5 to 125 PSI (3.5 to 8.5 bar). Standard Diaphragm Materials: NBR (Nitrile): Standard range, approx. -40°C to 82°C (-40°F to 180°F). Viton (FKM): High-temperature option, approx. -29°C to 232°C (-20°F to 450°F). Available Voltages: 24V DC, 110/120V AC, and 220/230V AC.
Common Uses & Maintenance Applications: Baghouses, cartridge dust collectors, silos, and pneumatic powder handling systems.
Rebuild / Spare Parts: Over time, the internal rubber diaphragm and spring can wear out, causing air leaks into the blowtube. standard replacement diaphragm kit: K2000 (or K2007 for Viton/high-temp setups).
Dimension of CA20T Goyen Type Pulse Jet Valve:
Technical data of Right Angle Pulse Jet Valves:
Integral Pilot Model No
CA15T
CA20T
CA25T
CA35T
CA45T
CA50T
CA62T
CA76T
Remote Pilot Model No
RCA15T
RCA20T
RCA25T
RCA35T
RCA45T
RCA50T
RCA62T
RCA76T
Orifice Size
(mm)
15
20
25
35
45
50
62
76
Port Size
(Inch)
1/2''
3/4''
1''
1-1/2''
1-1/2''
2''
2-1/2''
3''
Diaphragm Number
1
2
Working pressure
5 to 125 psi
Voltage
24VDC, 24VAC, 110VAC, 220VAC
Diaphragm Material
NBR(Standard), FKM(Option)
Body Material
Aluminum (diecast)
Valve Structure
Right Angle (Outlet is at 90° to Inlet)
Video of CA20T Goyen Type Pulse Jet Valve:
