CA76MM refers to a 3-inch (76 mm) submerged/full-immersion pulse jet valve (Goyen type MM series design). It is a high-flow diaphragm valve used in large industrial baghouses and dust collectors to blast high-volume compressed air into filter bags for reverse-pulse cleaning.
Like the CA50MM and CA62MM models, it mounts directly inside or onto flat surfaces of square or rectangular air tanks/headers, offering minimal flow resistance for maximum pulse efficiency.
Key Specifications & Characteristics
Port/Size: 3 inches (~76 mm)
Mounting Type: Submerged / Manifold Mount (MM Series)
Pressure Range: ~0.3 to 0.85 MPa (3 to 8.5 bar)
Temperature Range: Nitrile seals (-40°C to 82°C) or Viton seals (-29°C to 232°C for high-temp applications)
Control/Voltage: Integrated solenoid pilot available in 24V DC, 110V AC, or 220V AC
Common Variants & Accessories
RCA76MM: Remote-pilot version operated by an external solenoid enclosure rather than an attached solenoid.
K7600 / M7600: Standard replacement diaphragm repair kit for 3-inch Goyen-style valves.
Technical Data:
Integral Pilot
CA25MM
CA40MM
CA50MM
CA62MM
CA76MM
CA89MM
CA102MM
Remote Pilot
RCA25MM
RCA40MM
RCA50MM
RCA62MM
RCA76MM
RCA89MM
RCA102MM
Port Size
1''
1-1/2''
2''
2-1/2''
3''
3-1/2''
4''
Orifice Size
25mm
40mm
50mm
62mm
76mm
89mm
102mm
Pilot Size
1/8'', 1/4''
Body Material
Aluminum
Diaphragm Material
NBR (Standard), FKM (Optional)
Working Pressure
5 to 125 psi
Voltage
24VDC, 24VAC, 110VAC, 220VAC
Main Dimension of CA76MM Pulse Jet Valve:
Detail images of Goyen Type Pulse Jet Valves:
Video of CA76MM Goyen Type Pulse Jet Valve:
