1 Inch Goyen Type RCA25DD RCA25DD000 RCA25DD200 RCA25DD010 Dust Collector Valve

1 Inch Goyen Type RCA25DD RCA25DD000 RCA25DD200 RCA25DD010 Dust Collector Valve

The RCA25DD is a 1-inch, right-angle remote pilot pulse jet diaphragm valve, designed specifically for reverse pulse jet dust collector systems and baghouses.

Key Technical Specifications

Port Size / Diameter: 1 inch (25 mm nominal size)

Connection Type: Double dresser nut (compression fitting on both inlet and outlet ports)

Valve Structure: Right-angle (90° angle between inlet and outlet)

Body Material: Diecast aluminum alloy

Operating Pressure Range: 0.3 MPa to 0.8 MPa (approx. 5 to 125 psi)

Diaphragm Material: NBR (Buna/Nitrile) or FKM standard options

Operation Mode: Remotely piloted (requires a separate pilot solenoid valve)

Common Applications & Function

Dust Collection: Used to blast quick bursts of compressed air into filter bags to dislodge accumulated dust and clean the filters.

Fast Response: Engineered for high-flow capacity, fast diaphragm opening speed, and long operating life in harsh industrial environments.

Technical Data:

Main Dimension of RCA25DD Pulse Jet Valve:

Product Features:
1. Ready for use in any dust collector design
* For noxious substance control and environmental dust management

2. Cost savings
* Increased pulse efficiency, reduced energy consumption
* Durable materials and wide temperature range enhance lifespan
* Longer filter life, lower dust collector OPEX

3. Compliance
* With environmental and health & safety regulations

4. Ease of installation
* No welding required with 90° connections directly onto squaretanks

Related Products:

Fitting	Diaphragm	Remote Pilot Box	Pulse Controller
