ASCO Type G353A046 1 1/2 inch Air Control Remote Pilot Double Diaphragm Valve

ASCO Type G353A046 1 1/2 inch Air Control Remote Pilot Double Diaphragm Valve

The ASCO type G353A046 is a 1-1/2'' diaphragm pulse valve designed for reverse-pulse dust collector systems and industrial air filtration.

Key Technical Specifications

Ref: ASCO (Series 353)

Valve Type: 2/2-Way normally closed double-diaphragm pulse valve

Port / Pipe Size: 1-1/2" threaded connection (G 1-1/2" / BSP threads, DN40)

Operation: Solenoid / Remote pilot operated

Body Material: Die-cast aluminum

Operating Pressure: 0.35 to 8.5 bar (approx. 5 to 123 psi)

Primary Application: Dust collectors, baghouses, and air filtration systems

Comparison within Series 353

G353A041: 3/4" port size

G353A042: 1" port size

G353A045: 1-1/2" single-diaphragm model

G353A046: 1-1/2" double-diaphragm model (designed for higher peak pressure response and faster pulse cycles)

G353A046 Dimension:

Technical Data of 353 Series Pulse Jet Valves:

Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.
