G353A042 Remote Pilot Pulse Valve 1'' Single Diaphragm Air Control Pulse Valve

G353A042 Remote Pilot Pulse Valve 1'' Single Diaphragm Air Control Pulse Valve

The ASCO type G353A042 is a 1'' remote pilot diaphragm pulse valve designed for reverse-pulse baghouse dust collector systems.

Key Technical Specifications

Ref: ASCO Type (Series 353)

Valve Type: 2/2-Way normally closed diaphragm pulse valve

Port / Pipe Size: 1" threaded connection (G / BSP threads)

Operation: Remote pilot operated (1/8" pilot connection)

Body Material: Die-cast aluminum

Primary Application: Dust collector systems, air filtration, and bag filters

Key Difference vs. G353A041
While both belong to the same ASCO Series 353 family, the G353A042 features a larger 1" port size compared to the 3/4" port size on the G353A041.

G353A042 Dimension:

Technical Data of 353 Series Pulse Jet Valves:

Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.
