9mm Hole Pneumatic Solenoid Valve Coil With Cable Wire 12V 24V 110V 220V

There is pneumatic solenoid valve coil. When the valve is energized, the iron core is attracted by the coil and then moved to drive the spool to move, thereby changing the conduction state of the valve. Dry or wet is just the working environment of the coil, and there is no difference in valve operation.

But we must know that the amount of inductance is completely different after the air-core coil is added to the core. The inductance of the former is much smaller than that of the latter.

When the coil is connected to alternating current, the impedance produced by the coil is naturally different. For the same coil, when the same frequency of alternating current is applied, the inductance will change with the position of the core, that is, the impedance changes with the position of the core. When the impedance is small, the current flowing through the coil will increase.

So how does the solenoid valve coil use the wire to make an effect? In fact, it is built by the presence of a magnetic field around the wire, and it is wound into a spiral-shaped reinforcing magnetic field to achieve the highest magnetic field strength with a minimum space.

Dimension & Data of Pneumatic Solenoid Valve Coil:

BRANDO Solenoid Valve Coils Production Video:
