Hydac Type 3000489 3000249 300315 3002594 Hydraulic Solenoid Coil 12V 24V 110V 220V

This 40-1836 / E0241.H / 3000249 / 3003138 solenoid coil is a hydraulic coil for HYDAC type WSM06020 hydraulic valves. The electromagnetic coil and the armature assembly form an electromagnet. The electromagnet is the energizing solenoid that is learned in middle school. It generates magnetism after being energized. However, it also generates heat after energization. The higher the power of the electromagnet, the greater the heat generated. The heat generated is always more than the heat emitted. It will continue to heat up. When the temperature reaches a certain height, the paint layer on the melt will melt, and then the short circuit will burn out. The electromagnet coil has a thermal effect in addition to the magnetic effect when it is energized. This is inevitable.

Dimension of Hydraulic Solenoid Valve Coil:

Applied in HYDAC Type WSM06020 ELectro Valve 3003138 / 3000249 Solenoid Coil:

DIN43650A connection type Hydac type hydraulic coil for you to choose:
