BDA ODE Type Solenoid Valve Coil AC220V 8W AC220V 14.5VA

BDA ODE Type Solenoid Valve Coil AC220V 8W AC220V 14.5VA

  • BDA ODE Type Solenoid Valve Coil AC220V 8W AC220V 14.5VA
  • BDA ODE Type Solenoid Valve Coil AC220V 8W AC220V 14.5VA
BDA ODE Type Solenoid Valve Coil AC220V 8W AC220V 14.5VA
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: None
Model Number: BB10239027
Payment & Shipping Terms:
Minimum Order Quantity: 200
Price: Negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: Negotiation
Payment Terms: T/T,PayPal,Western Union
Supply Ability: 250000 pieces per month
Contact Now
Detailed Product Description
Product Name: Solenoid Valve Coil Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 120VAC, 220VAC, 230VAC, 240VAC, 380VAC
Connector: DIN43650A Power: 8W, 11W, 14.5VA, 15VA, 16VA, 17VA
Reference Number: BDA08012AS, BDA08024DS, BDA08110DS, BDA08223DS, BDA08380DS, BDV08024DY, BDV08110AY, BDV08230AY, BSA08223DS, BVA08223DS, BDA08012CS, BDA08024CS, BDV08024CY Ordering Code: BDA
Highlight:

BDA Solenoid Valve Coil

,

ODE Solenoid Valve Coil

,

BDA Electrical Solenoid Coil

BDA ODE Type Solenoid Valve Coil AC220V 8W AC220V 14.5VA




This BDA solenoid coil is popularly used for ODE solenoid valves. Solenoid Coil Standard Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 120VAC, 220VAC, 230VAC. Solenoid Coil Standard Power: 8W, 11W, 14.5VA, 15VA, 16VA, 17VA. The solenoid coil is integral in the operation of a solenoid valve. It is what converts the electric current into a magnetic field which in turn allows the operation of the solenoid valve.


Dimension & Data of BDA Solenoid Coil, Armature:

BDA ODE Type Solenoid Valve Coil 12V 24V DC 110V 120V 220V 230V AC 0

BRANDO Model
BB13239027
Voltage


12VDC, 24VDC, 24VAC,

110VAC, 220VAC
Power
8W, 11W, 14.5VA, 15VA, 16VA, 17VA
Other voltage and power can be customized
Insulation Class
F, H
Connector
DIN43650A


BDA ODE Type Solenoid Valve Coil 12V 24V DC 110V 120V 220V 230V AC 1

BRANDO Model
BAPC313054054
Function
 3 Way Normally Closed
Plunger Tube Material
Stainless Steel
Seal Material
NBR, EPDM, FKM
Connection Type
Thread


Reference Number of BDA Solenoid Coil:

Code
Power (VA)
AC Voltage
(Volt)
Frequency
(Hz)
ED
(%)
Ambient
Temperature
Irush
holding
BDA08012AS
14.5
25
12V AC
50
100
-10℃ to +40℃
BDA08024DS
14.5
25
24V AC
50/60
100
-10℃ to +40℃
BDA08110DS
14.5
25
110V AC
50/60
100
-10℃ to +40℃
BDA08223DS
14.5
25


220V AC

230V AC
50/60
100
-10℃ to +40℃
BDA08380DS
14.5
25
380V AC
50/60
100
-10℃ to +40℃
BDV08024DY
17
25
24V AC
50/60
100
-20℃ to +60℃
BDV08110AY
15
25
110V AC
120V AC
50
60
100
-20℃ to +60℃
BDV08230AY
16
25
230V AC
240V AC
50
60
100
-10℃ to +40℃
BSA08223DS
14.5
25
220/230V AC
50/60
100
-10℃ to +40℃
BVA08223DS
14.5
25
220/230V AC
50/60
100
-10℃ to +40℃


Code

Power

(W)

DC Voltage

(Volt)

ED

(%)
Ambient
Temperature
BDA08012CS
8
12V DC
100
-10℃ to +40℃
BDA08024CS
8
24V DC
100
-10℃ to +40℃
BDV08024CY
11
24V DC
100
-20℃ to +60℃


Video of Solenoid Valve Coil BDA:


BRANDO Solenoid Valve Coils Production Video:


More Solenoid Valves for you to choose:

a2 a4 a5
Brass Solenoid Valve Stainless Steel Solenoid Valve Plastic Solenoid Valve


Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
